Product Overview
TheGE 1C31166G02is a critical analog input module designed for GE’s Mark VI Speedtronic turbine control system,serving as a vital interface for analog signal processing in gas and steam turbine applications.This high-reliability module forms an essential component in the turbine protection and control chain,ensuring precise measurement of critical parameters including temperature,pressure,and flow rates.TheGE 1C31166G02features advanced signal conditioning capabilities with high accuracy and stability,making it suitable for the demanding requirements of power generation environments where measurement precision directly impacts operational safety and efficiency.Its robust design and compliance with stringent industrial standards ensure reliable performance in the challenging conditions typical of turbine control applications.
Engineered to meet the rigorous demands of continuous operation in power generation facilities,theGE 1C31166G02incorporates sophisticated signal processing technology that maintains accuracy across wide temperature ranges and under electrical noise conditions.The module’s design focuses on fail-safe operation and diagnostic capabilities,providing early warning of potential issues before they impact system performance.As part of GE’s comprehensive Speedtronic control system,theGE 1C31166G02delivers the measurement reliability needed for critical turbine control functions,contributing to overall plant safety and operational availability.The module’s compatibility with the Mark VI platform ensures seamless integration into both new installations and existing control system upgrades.
Technical Specifications
Parameter Name
Parameter Value
Product Model
GE 1C31166G02
Manufacturer
General Electric(GE)
Product Type
Analog Input Module
Control System
Mark VI Speedtronic
Input Channels
8 analog inputs
Input Types
Voltage/Current(configurable)
Input Range
±10V,0-10V,4-20mA,0-20mA
Resolution
16-bit
Accuracy
±0.1%of full scale
Update Rate
10ms per channel
Isolation
Channel-to-channel:1500V AC
Common Mode Rejection
>120dB
Input Impedance
Voltage:1MΩ,Current:250Ω
Power Supply
24V DC nominal
Operating Temperature
-40°C to+70°C
Storage Temperature
-55°C to+85°C
Communication Interface
VMEbus
Protection Class
IP20(rack mounted)
Certifications
UL,CE,cULus
Main Features and Advantages
High Precision Measurement:TheGE 1C31166G02delivers exceptional measurement accuracy with 16-bit resolution and±0.1%full-scale accuracy,ensuring precise monitoring of critical turbine parameters.The module’s advanced analog-to-digital conversion technology provides stable,repeatable measurements while sophisticated filtering algorithms suppress noise and interference.Each channel can be independently configured for voltage or current input,offering flexibility for various sensor types and signal conditions.The high-impedance inputs minimize loading effects on signal sources,while the current inputs include built-in signal conditioning for direct connection of process instruments.
Robust Industrial Design:Designed for harsh power generation environments,theGE 1C31166G02features comprehensive isolation between channels and from the system bus,preventing ground loops and noise propagation.The module’s wide operating temperature range(-40°C to+70°C)ensures reliable performance in extreme conditions,while protection against overvoltage and reverse polarity enhances system durability.The rugged construction and compliance with industrial standards make theGE 1C31166G02suitable for continuous operation in critical turbine control applications where reliability is paramount.
Advanced Diagnostic Capabilities:TheGE 1C31166G02incorporates comprehensive diagnostic features that monitor module health and signal integrity.Continuous self-testing routines verify proper operation,while status indicators provide immediate visual feedback of operational status.The module supports open wire detection for current inputs and out-of-range monitoring for all channels,enabling proactive maintenance before issues impact turbine operation.Detailed diagnostic information available through the control system facilitates rapid troubleshooting and reduces mean time to repair.
Application Field
Gas Turbine Control:In combined cycle and simple cycle power plants,theGE 1C31166G02monitors critical parameters including exhaust temperature,fuel pressure,and compressor discharge pressure.The module’s high accuracy and reliability ensure precise control of turbine operation,contributing to efficient power generation and equipment protection.TheGE 1C31166G02is particularly valuable in applications requiring multiple analog measurements where measurement integrity directly impacts turbine performance and availability.
Steam Turbine Systems:In conventional and nuclear power plants,theGE 1C31166G02provides accurate monitoring of steam pressure,temperature,and flow parameters.The module’s stability and precision support efficient turbine operation and contribute to overall plant safety.In cogeneration applications,theGE 1C31166G02helps optimize energy recovery by providing reliable measurements for process control and performance monitoring.
Industrial Drive Applications:For large compressor and pump drives in pipeline and process applications,theGE 1C31166G02monitors process variables and equipment conditions.The module’s robust design withstands the vibration and electrical noise typical in industrial drive environments,while its measurement accuracy ensures reliable operation of critical machinery.
Related Products
GE 1C31166G01:Previous version analog input module
GE 1C31166G03:Enhanced version with additional features
GE 1C31203G01:Digital input module
GE 1C31204G01:Digital output module
GE 1C31224G01:Communication interface module
GE IS200 series:Additional Speedtronic components
GE Mark VI system:Complete control system platform
Installation and Maintenance
Pre-installation preparation:Before installing theGE 1C31166G02,verify compatibility with the Mark VI rack system and ensure proper power supply capacity.Review system documentation to plan channel assignments and configuration parameters.Ensure proper grounding practices are followed and that signal cables are appropriately shielded and routed to minimize noise interference.Configure the module parameters in the control system software before installation to ensure proper operation upon system startup.
Maintenance recommendations:Regularly monitor theGE 1C31166G02status indicators and diagnostic information through the control system to verify normal operation.Periodically verify calibration by comparing module readings against known reference standards,particularly for critical measurement points.During routine maintenance,inspect connections for tightness and corrosion,and ensure adequate ventilation around the module.Maintain current backups of the configuration and follow GE’s recommended practices for firmware updates and preventive maintenance.
Product Guarantee
We guarantee that everyGE 1C31166G02module meets original manufacturer specifications and undergoes comprehensive testing before shipment.Each unit is backed by our technical support team with extensive experience in GE Speedtronic systems and power generation applications.Our commitment includes accurate configuration guidance,complete documentation packages,and replacement assurance for any modules that do not perform to specification.With specialized expertise in turbine control systems,we provide practical guidance for implementing theGE 1C31166G02in your specific application environment,ensuring reliable operation and optimal performance for your critical control requirements.
