ABB 3BHL000986P7000 LXN1604-6 Product Introduction

Product Description

The ABB 3BHL000986P7000 LXN1604-6 is a high-performance industrial communication module designed for seamless integration of automation devices into modern control systems. It provides reliable Ethernet communication capabilities, enabling efficient data exchange between field devices and central control systems. This module is part of ABB’s comprehensive portfolio of automation solutions and is designed to support Industry 4.0 concepts and digital transformation initiatives.

Technical Specifications

表格

复制
Parameter Value
Product Model LXN1604-6
Manufacturer ABB
Product Type Industrial Ethernet Communication Module
Communication Protocol EtherNet/IP, PROFINET, Modbus TCP
Number of Ports 4 x 10/100Base-T(X) Ethernet ports
Power Supply 24 VDC (±10%)
Power Consumption 5 W maximum
Operating Temperature -25°C to +60°C
Storage Temperature -40°C to +85°C
Dimensions 100 mm (H) x 90 mm (W) x 50 mm (D)
Weight 0.5 kg
Protection Rating IP20
Mounting DIN rail (35 mm) or panel mounting
Compliance CE, UL, FCC Class A
Certifications ISO 9001, IEC 61000-6-2, IEC 61000-6-3

Key Features and Benefits

  • Multi-Protocol Support: Supports EtherNet/IP, PROFINET, and Modbus TCP, ensuring compatibility with a wide range of automation systems.
  • Flexible Connectivity: Four high-speed Ethernet ports support daisy-chain, star, and ring network configurations.
  • Advanced Diagnostics: Real-time monitoring of network performance, port status, and data traffic for proactive maintenance.
  • Robust Design: Wide operating temperature range and IP20 protection rating ensure reliability in harsh industrial environments.
  • Energy Efficiency: Incorporates power factor correction and energy-saving modes to reduce energy consumption.

Function

The ABB 3BHL000986P7000 LXN1604-6 serves as a critical communication bridge in automation architectures. It enables real-time monitoring and control, improving overall system performance and reducing downtime.

Applications

The ABB 3BHL000986P7000 LXN1604-6 is widely used in:
  • Power Generation: Connecting turbines, generators, and auxiliary equipment to central control systems.
  • Process Industries: Facilitating communication between DCS, PLC, and field instruments in chemical and petrochemical plants.
  • Discrete Manufacturing: Implementing automation for production lines, robotic systems, and conveyor controls.
  • Water and Wastewater Treatment: Connecting pump controls, valve actuators, and instrumentation.
  • Mining and Minerals Processing: Connecting heavy equipment monitoring systems and safety instrumentation.

Application Fields

  • Industrial Automation: For precise control and monitoring in manufacturing and production facilities.
  • Process Control: For monitoring and control of chemical, petroleum, and food and beverage processes.
  • Building Automation: For controlling HVAC, lighting, and security systems.
  • Energy Management: For managing power generation, transmission, and distribution systems

ABB 3BHL000986P7000 LXN1604-6

ABB 3BHL000986P7000 LXN1604-6
