Product Overview

The ABB 3BSE008514R1 DO820is a high-performance digital output module designed for ABB’s industrial automation systems,providing reliable control signal output for various industrial applications.This advanced 16-channel digital output module serves as a critical interface between control systems and field actuators,ensuring precise control of industrial processes.The DO820 3BSE008514R1exemplifies ABB’s commitment to industrial automation excellence through its robust construction and reliable performance in demanding industrial environments where control accuracy and system reliability are paramount for operational success.

Engineered with industrial-grade components and advanced output technology,the ABB 3BSE008514R1 DO820delivers stable and precise control signals to actuators,valves,motors,and other field devices.The module’s high-density design incorporates 16 independent output channels,each capable of switching significant loads while maintaining electrical isolation and protection.Implementation of the DO820 3BSE008514R1in control systems demonstrates ABB’s expertise in creating reliable automation solutions that enhance system performance while reducing installation complexity across various industrial sectors including manufacturing,process control,and energy management.

Technical Specifications

Parameter Name

Parameter Value

Product Model

DO820 3BSE008514R1

Manufacturer

ABB

Product Type

Digital Output Module

Channels

16 channels

Output Type

24VDC sourcing

Output Current

0.5A per channel

Max Total Current

8A(all channels)

Load Voltage

24VDC(20.4-28.8VDC)

Power Dissipation

1.1W typical

Response Time

<1ms

Isolation

500VAC channel to channel

Protection

Short-circuit,overload,overtemperature

Status Indicators

Per-channel LED

Connection

Removable terminal block

Power Supply

Backplane powered

Operating Temperature

0°C to+60°C

Storage Temperature

-40°C to+85°C

Relative Humidity

5%to 95%non-condensing

Certifications

UL,cULus,CE

Dimensions

120mm×130mm×70mm

Weight

0.4kg

Main Features and Advantages

High-Density Output Configuration:The ABB 3BSE008514R1 DO820provides 16 independent digital output channels in a compact module design,offering space-efficient control solution for high-point-count applications.Each channel delivers 0.5A switching capacity at 24VDC,suitable for driving various industrial actuators,solenoids,and relays.The module’s high-density design optimizes control cabinet space utilization while maintaining excellent thermal performance through efficient heat dissipation design.

Advanced Protection Features:Engineered for reliability,the ABB 3BSE008514R1 DO820incorporates comprehensive protection mechanisms including short-circuit protection,overload protection,and overtemperature shutdown.Each output channel features individual protection that prevents fault propagation to other channels.The module’s robust design ensures reliable operation in electrically noisy industrial environments,with 500VAC channel-to-channel isolation providing enhanced system safety and noise immunity.

Intelligent Diagnostics and Monitoring:The ABB 3BSE008514R1 DO820features per-channel status indicators that provide immediate visual feedback on output status.Advanced diagnostic capabilities monitor output conditions and detect faults such as short circuits or open loads,enabling quick troubleshooting and reducing system downtime.The module’s diagnostic information is accessible through the control system,supporting proactive maintenance strategies.

Flexible System Integration:Designed for seamless integration with ABB’s control systems,the DO820 3BSE008514R1supports easy configuration and commissioning through standard engineering tools.The removable terminal block simplifies wiring and maintenance,while the module’s hot-swappable design(in supported systems)allows for maintenance without system shutdown.These features significantly reduce installation time and maintenance costs.

Application Field

In manufacturing automation systems,the ABB 3BSE008514R1 DO820is extensively used for controlling pneumatic valves,motor starters,and indicator lights in production equipment.The module’s fast response time(<1ms)ensures precise timing control in high-speed automation applications,while its robust output capability drives various industrial actuators reliably.In automotive assembly lines,the DO820 3BSE008514R1provides reliable control for clamping cylinders and conveyor stops,contributing to production efficiency and quality.

Process industry applications utilize the ABB 3BSE008514R1 DO820for controlling motor-operated valves,solenoid valves,and alarm indicators in chemical plants and refineries.The module’s high reliability and protection features ensure safe operation in critical process control applications.The DO820’s individual channel isolation prevents fault propagation,maintaining system availability even in case of individual channel failures.

Material handling and packaging systems employ the ABB 3BSE008514R1 DO820for controlling conveyor motors,sorting gates,and packaging equipment.The module’s compact design and high channel density make it ideal for space-constrained control panels,while its robust construction withstands the vibration and electrical noise common in material handling environments.

Related Products

ABB DI810-Digital input module

ABB AI810-Analog input module

ABB AO810-Analog output module

ABB CI871-Communication interface

ABB TU810-Terminal unit

ABB SD812-System drive module

ABB CP640-Control panel

ABB AC800M-Controller family

Installation and Maintenance

Installation preparation:Before installing the ABB 3BSE008514R1 DO820,verify compatibility with the existing control system and ensure proper module seating in the baseplate.Confirm that all field wiring uses appropriate wire sizes and follows local electrical codes.Ensure adequate clearance around the module for proper heat dissipation and accessibility for maintenance.

Maintenance recommendations:Regular maintenance of the ABB 3BSE008514R1 DO820should include periodic inspection of terminal connections for tightness and cleanliness.Monitor status indicators during operation and address any fault indications promptly.Keep spare modules available for critical applications to minimize downtime in case of failure.

Product Guarantee

We guarantee that every ABB 3BSE008514R1 DO820module we supply is a genuine ABB component that meets all original manufacturer specifications.Our technical support team provides comprehensive assistance with module configuration,system integration,and troubleshooting.We stand behind the quality and performance of the DO820 3BSE008514R1modules we provide,ensuring they deliver the reliable operation expected from ABB automation systems.
