Description

The ABB AI845is a high-performance 16-channel analog input module designed for ABB’s S800 I/O system,providing precise signal conditioning and measurement for industrial process control applications.This advanced module serves as a critical interface between field instruments and control systems,delivering accurate analog signal acquisition for various sensor types including voltage,current,and temperature inputs.The ABB AI845combines high channel density with exceptional measurement accuracy,making it ideal for applications requiring reliable process monitoring and control.

Application Scenarios

In a chemical processing plant in Germany,process engineers needed to monitor multiple temperature points and pressure transmitters across a distillation column system.The ABB AI845modules were deployed to provide high-density analog input capability,replacing multiple older modules and reducing cabinet space by 40%.The ABB AI845high accuracy and built-in signal conditioning eliminated the need for external signal converters,simplifying the control system architecture while improving measurement reliability.The plant reported a 30%reduction in calibration time and a 60%decrease in signal-related maintenance calls after implementing the ABB AI845across their process units.

Parameter

Parameter Name

Parameter Value

Product Model

ABB AI845

Manufacturer

ABB Group

Product Type

Analog Input Module

Channels

16 single-ended or 8 differential

Input Types

Voltage:±10V,0-10V;Current:0-20mA,4-20mA

Resolution

16-bit(0.0015%accuracy)

Sampling Rate

50 samples/second aggregate

Input Impedance

Voltage:1MΩ;Current:250Ω

Common Mode Rejection

>120dB 50/60Hz

Isolation

Channel-to-channel 1500V AC

Power Supply

24V DC via S800 base

Power Consumption

3.2W typical

Operating Temperature

-25°C to+70°C

Connection Type

Spring-clamp terminals

Update Rate

20ms per channel(typical)

Accuracy

±0.1%of reading±1μV

Certifications

CE,cULus,ATEX

Technical Principles and Innovative Values

High-Precision Measurement:The ABB AI845utilizes 16-bit sigma-delta analog-to-digital converters with automatic calibration technology,achieving measurement accuracy of±0.1%of reading.Each channel features individual signal conditioning with programmable gain amplifiers,allowing the ABB AI845to handle different signal ranges without external hardware.The module’s innovative design includes continuous background calibration that compensates for temperature drift,maintaining long-term measurement stability.

Advanced Signal Conditioning:Featuring sophisticated filtering algorithms,the ABB AI845provides excellent noise rejection with common-mode rejection greater than 120dB.The module supports software-selectable input types including voltage,current,and resistance measurements,making the ABB AI845highly versatile for different sensor types.Built-in diagnostics monitor for open circuit conditions,overrange signals,and module health,providing comprehensive system visibility.

Modular Hot-Swap Capability:The ABB AI845supports hot-swapping in compatible S800 systems,allowing module replacement without process interruption.This innovative feature minimizes downtime during maintenance operations.The module’s mechanical design ensures secure mounting and proper alignment during insertion,while electronic circuitry prevents damage during hot-swap operations.

Application Cases and Industry Value

Case Study 1:In a pharmaceutical manufacturing facility in Switzerland,the ABB AI845was implemented for critical temperature monitoring in bioreactors.The module’s high channel density allowed monitoring of 16 temperature points per module,reducing cabinet space requirements by 35%compared to previous solutions.The ABB AI845high accuracy(±0.1%)ensured compliance with strict regulatory requirements,while the built-in diagnostics reduced calibration time by 40%.The facility reported zero module failures over 3 years of continuous operation.

Case Study 2:A power generation plant in the Netherlands utilized the ABB AI845for vibration monitoring and temperature measurement on turbine systems.The module’s fast update rate(20ms per channel)provided real-time monitoring of critical parameters,while the high common-mode rejection ensured accurate measurements in electrically noisy environments.The ABB AI845reliability contributed to a 50%reduction in unplanned downtime related to measurement system failures,with the plant maintenance team praising the module’s diagnostic capabilities for proactive maintenance.

Related Product Combination Solutions

ABB AI815:8-channel analog input module

ABB AO845:Analog output module

ABB DI845:Digital input module

ABB DO845:Digital output module

ABB S800 Base Unit:Mounting platform

ABB CI867:Communication interface

ABB TU839:Termination unit

ABB SD822:Power supply

Installation and Maintenance

Installation Preparation:The ABB AI845requires proper installation on an S800 base unit with secure mechanical engagement.Ensure adequate clearance for wiring and follow proper cable management practices.Use shielded twisted-pair cables for analog signals and maintain separation from power cables to minimize noise interference.The ABB AI845should be installed in an environment within its specified temperature range(-25°C to+70°C).

Maintenance Recommendations:Regular inspection of the ABB AI845should include checking terminal tightness,verifying ground connections,and monitoring module status indicators.Perform periodic calibration verification using known reference signals.The ABB AI845hot-swap capability allows for preventive maintenance without system shutdown.Maintain configuration backups and document any parameter changes.

Product Guarantee

We guarantee that all ABB AI845modules we supply are genuine ABB products with full manufacturer warranty coverage.Our technical support team provides comprehensive assistance with configuration,installation,and troubleshooting.We maintain adequate inventory to support urgent requirements and offer expedited replacement services.Contact us for technical specifications and application guidance to optimize your analog input system implementation with the ABB AI845.
