Product Overview

The ABB CI867K01 3BSE043660R1 is a high-performance communication interface module designed for industrial automation systems, enabling high-speed data exchange and communication between different devices and systems. This module supports multiple communication protocols, including Modbus TCP/IP, Ethernet IP, PROFINET IO, DNP3, IEC 60870-5-103/104, and SNMP, meeting the communication needs of complex industrial environments.

Key Technical Parameters

Parameter Item

Specification

Product Model

ABB CI867K01 3BSE043660R1

Manufacturer

ABB

Product Type
Communication Interface Module

Mounting Method

DIN Rail Mounting

Power Supply Voltage

24V DC (Typical)

Operating Temperature

-25°C to +70°C

Storage Temperature

-40°C to +85°C

Relative Humidity

5% to 95%, Non-condensing

Dimensions
127.5 × 186 × 59 mm

Weight
0.7 kg

Protection Rating

IP20

Certifications

CE, UL, RoHS

Core Features

High-Performance Communication Capability

The CI867K01 module supports communication rates up to 100Mbps, ensuring real-time and reliable data exchange. Featuring a dual-channel design, supporting full-duplex communication, channel 1 supports 10/100 Mbit/s, and channel 2 supports 10 Mbit/s.

Protocol Compatibility

This module supports multiple industrial communication protocols, including Modbus TCP, Profinet, and EtherNet/IP, adapting to different industrial environment requirements. It supports master-slave mode, connecting up to 70 slave devices.

Industrial-Grade Reliability

Equipped with an industrial-grade design, it boasts excellent anti-interference and stability, suitable for harsh industrial environments. Hot-swappable functionality allows module replacement without interrupting system operation.

Intelligent Diagnostic Functions

Built-in intelligent diagnostic tools help users quickly identify and resolve potential technical problems. Equipped with 6 dual-color LED status indicators, providing clear display of operating status.

Application Areas

Industrial Automation

The CI867K01 is widely used in industrial automation production lines to achieve communication and data exchange between devices, improving production efficiency. It is particularly suitable for applications requiring high performance, high reliability, and complex control.

Power Systems

In power generation control and protection systems, this module is used to monitor and control power grid equipment, ensuring stable and safe power supply.

Process Industries

In process control systems in industries such as petroleum, chemical, and pharmaceutical, the CI867K01 provides precise control and monitoring functions, improving production efficiency and safety.

Water Treatment Systems

In the automation of water supply and wastewater treatment facilities, this module enables water quality monitoring and control, as well as flow and pressure signal processing.

Technical Advantages

Modular Design

Adopts a compact modular design for easy installation and maintenance. Supports DIN rail mounting, offering flexible installation and reducing system complexity.

Electrical Isolation

Provides electrical isolation between inputs and outputs, preventing surge and noise interference and protecting sensitive equipment.

Redundant Configuration

Supports redundant configurations, allowing the addition of redundant components in critical parts to improve system reliability and stability.

System Integration

The CI867K01 is fully compatible with ABB’s 800xA and AC500 automation platforms, enabling seamless integration with ABB automation solutions. It also supports seamless connectivity with other third-party systems such as PLCs, HMIs, and SCADA systems.

Installation and Maintenance

Installation Requirements

The module should be installed on a standard 35mm DIN rail, ensuring the operating environment meets temperature and humidity requirements. Use appropriate cable specifications and follow the manufacturer’s recommended installation guidelines.

Maintenance Recommendations

Regularly check the module status indicator lights and perform functional tests. When replacing modules, ensure the system is powered off or use hot-swapping to avoid damaging the equipment.

The ABB CI867K01 3BSE043660R1, with its superior performance and reliability, has become an important component in the field of industrial automation communication, providing stable and efficient communication solutions for various industrial applications.
