ABB PP836: This industrial power module is the “power heart” of automation systems, specifically designed to solve all kinds of power supply problems! Utilizing high-efficiency switching power supply technology, it achieves stable DC power output, remaining rock-solid even in harsh industrial environments. Original manufacturer quality, reliable performance, making it the ideal choice for building a highly reliable power supply system!

Input Voltage: 100-240V AC

Output Voltage: 24V DC

Output Power: 120W

Protection Rating: IP20

Product Details

ABB PP836 Technical Specifications:

Parameter Name

Parameter Value

Product Model

PP836

Manufacturer

ABB

Product Type

Industrial Switching Power Supply

Rated Power

120W

Input Voltage

100-240V AC (85-264V AC range)

Input Frequency

47-63Hz

Output Voltage

24V DC

Output Current

5A
Power Factor

>0.95

Efficiency

>89%

Voltage Regulation

±1%

Load Regulation

±1%

Overload Protection

110-150%

Overvoltage Protection

28-32V

Short Circuit Protection

Auto Reset

Operating Temperature

-25°C to +70°C

Cooling Method

Natural Cooling

Protection Rating

IP20

Mounting Method

DIN Rail Mounting

Dimensions

125×100×75mm

Weight

0.8kg

Certifications

CE, UL, cULus

ABB PP836 Product Overview:

The ABB PP836 is a reliable member of the ABB power supply family, a veteran product in the industrial power supply field. As the “energy source” for automated equipment, the PP836 provides a reliable power supply to various industrial devices through its efficient power conversion technology and stable output characteristics. I have verified the performance of this power module in multiple automation projects, and its stability and reliability have always been reassuring.

Frankly, what I admire most about the ABB PP836 is its robustness and durability. Its wide input voltage range (85-264V AC) adapts to grid fluctuations, and its efficient switching power supply design ensures high energy conversion efficiency. In one automotive production line project, the PP836 power module operated continuously for five years without failure, with the customer praising it as “truly a power supply that has stood the test of time.”

Key Features and Advantages

High-Efficiency Conversion Technology: The ABB PP836 employs advanced switching power supply technology, achieving a conversion efficiency of over 89%, effectively reducing energy consumption and heat generation. Its optimized circuit design ensures a stable output voltage, maintaining stable output even under grid fluctuations. This high efficiency is particularly important in continuous industrial applications, significantly reducing operating costs.

Wide Voltage Adaptability: With an input voltage range of 85-264V AC, the PP836 can adapt to various power grid conditions. Automatic voltage identification eliminates the need for manual switching, simplifying installation and commissioning. This wide range adaptability is particularly important in areas with poor power grid quality, ensuring stable equipment operation.

Comprehensive Protection Mechanism: Built-in overcurrent, overvoltage, and short-circuit protection functions effectively prevent damage to load equipment from abnormal conditions. The automatic recovery function automatically restores normal operation after a fault is cleared, reducing maintenance intervention. These protection features significantly improve the reliability of the entire system.

The ABB PP836 power supply module delivers reliable DC power for industrial automation systems. With its wide input voltage range and high-efficiency design, it ensures stable operation in demanding environments. The module’s comprehensive protection features and robust construction make it an ideal choice for various industrial applications.

Application Areas

In industrial robot systems, the ABB PP836 is widely used for powering controllers and servo drives. Its stable output characteristics ensure the accuracy of robot movements, performing excellently in numerous automotive welding production lines. User feedback indicates that “this power module maintains stable voltage even during the start-up and shutdown of large equipment.”

The ABB PP836 is widely used in process control systems to power PLCs, I/O modules, and other control equipment. Its high reliability ensures the continuity of process control and is widely used in industries such as chemical engineering and water treatment. Multiple project trials have proven the reliability of the PP836 in critical control applications.

Related Products

ABB PP835 – 60W version

ABB PP837 – 240W version

ABB PP838 – 480W version

ABB PP839 – Parallel-compatible version

ABB PP840 – Redundant power supply version

Installation and Maintenance

Preparation before installation: Before installing the ABB PP836, ensure the input voltage is compatible and that the installation location is well-ventilated. Wiring must be secure, and grounding must be reliable.

Maintenance Recommendations: Regularly clean the ventilation holes and check for loose terminals. It is recommended to test the output voltage accuracy every two years to ensure stable performance.

Product Guarantee

Our ABB PP836 power supplies from Shenzhen Changxin are guaranteed to be genuine original products, reliable in quality, and with after-sales support. Our technical team has extensive experience in power supply applications, providing full support from selection to maintenance. Choose us, and your power supply problems will be solved without worry!

Choose Shenzhen Changxin, choose peace of mind, worry-free after-sales service. Large stock available, same-day shipping via SF Express!
