GE 516TX 336A4940DNP516TX

Product Description

Product Parameters

• Part Number: 336A4940DNP516TX
• Manufacturer: General Electric
• Series: N-Tron 516 TX
• Ports: 16 ports (10/100BaseTX RJ-45)
• MAC Address Capacity: 4000
• Aging Time: 300 seconds
• Backplane Speed: 2.6 Gb/s
• Switching Method: Store and Forward
• Operating Temperature: -40°C to 85°C
• Storage Temperature: -40°C to 85°C
• Operating Humidity: 10% to 95% (non-condensing)
• Operating Altitude: 0 to 10,000 ft
• Dimensions: 2.3″ (H) x 7.4″ (W) x 3.5″ (D)
• Weight: 2.2 lbs (1.0 kg)
• Power Input: Redundant power input (10-30VDC)
• Compliance: FCC/CE, EMC Dir 89/336/EEC, EN 50204, EN 55011, EN61000-6-2/4 ANSI C63.4, ICES-003, UL/cUL: Class I, Div 2, Groups A, B, C, D and T4A, UL 508 and UL 1604, CAN/CSA-C22.2 No.213, ATEX II 3 G Ex nA, ABS Type Approval, GOST-R Certified, RoHS Compliant.

Product Specifications

• Compliance: IEEE 802.3 and 1613, NEMA TS1/TS2, American Bureau of Shipping (ABS) Type Approval.
• Features: Auto-sensing 10/100BaseTX, full/half duplex, MDIX; redundant power inputs; dual-color LED indicators for link, speed, activity, and duplex status.

Series

Features

• Advanced Management Functions (with -A option): IGMP Snooping, VLAN, QoS, Trunking, Port Mirroring, and N-ViewTM (remote monitoring via OPC technology).
• Robust Design: Built to withstand extreme conditions, with a wide operating temperature range and compliance with multiple industrial standards.

Functions

• Network Connectivity: Connects industrial devices supporting Ethernet.
• Data Transmission: Ensures reliable data transfer in industrial environments.
• System Integration: Integrates with GE Mark VIe control systems and other industrial networks.

Uses

• Industrial Automation: For device status monitoring and process control in factories.
• Process Control Industries: Monitoring process variables in chemical plants and water treatment facilities.
• Building Automation: Controlling lighting, HVAC, and other building systems.
• Energy Sector: Power distribution, hydroelectric, and thermal power plants.
• Transportation Systems: Traffic signal control.

Application Fields

• Industrial Automation
• Process Control
• Building Automation
• Energy Sector
• Transportation

GE SR750-P5-G1-S1-HI-A20-R

Product Description

Product Parameters

• Model Number: SR750-P5-G1-S1-HI-A20-R
• Manufacturer: GE Multilin
• Series: 750/760 Feeder Management Relays
• Operating Voltage: 220 V AC
• Frequency Range: 25-60 Hz
• Phase Current Input: 5A
• Zero-Sequence Current Input: 1A
• Sensitive Ground Input: 1A
• Analog Outputs: 4-20mA
• Display Type: Basic
• Operating Temperature Range: -40°C to 60°C
• Weight: 7.9 kg

Product Specifications

• Communication Protocols: Modbus RTU/DNP 3.0
• Certifications: CE
• Manual Code: GEK-106471N

Series

Features

• Comprehensive Protection: Provides protection against overloads, faults, and voltage irregularities.
• Advanced Monitoring: Features metering functions to monitor voltage, frequency, watt-hour cost, load travel percentage, and more.
• User-Friendly Interface: Equipped with a 40-character LCD display, keyboard, and LED indicators for easy configuration and status monitoring.
• Security: Password protection to prevent unauthorized adjustments.
• Wide Operating Range: Suitable for IP40-level conditions and a wide temperature range.

Functions

• Feeder Management: Monitors and protects distribution feeders and associated equipment.
• Data Acquisition: Collects and processes data for real-time monitoring and analysis.
• Control and Communication: Facilitates control functions and data exchange with other systems using supported protocols.

Uses

• Power Distribution Networks: In manufacturing plants, substations, and utility facilities.
• Power Generation: Protecting feeders, transformers, and generators.
• Industrial Automation: Ensuring reliable energy distribution in industrial settings.

Application Fields

• Power Generation
• Manufacturing
• Utility Facilities
• Industrial Automation

Product Description

Product Parameters

• Model Number: V7768-320001
• Processor Options:
  • Intel Core 2 Duo @ 2.16 GHz
  • Intel Celeron M @ 1.07 GHz
• Cache:
  • 4 MB (Core 2 Duo)
  • 1 MB (Celeron M)
• Memory: Up to 2 GB DDR2 SDRAM via single SODIMM
• Storage:
  • Bootable CompactFlash up to 8 GB
  • SATA interfaces for additional storage
• Operating Voltage: 24V DC
• Power Consumption: Approximately 100W
• Operating Temperature Range: -40°C to +85°C
• Dimensions: 233 mm x 167 mm x 30 mm
• Weight: Approximately 0.5 kg

Product Specifications

• I/O Interfaces:
  • Dual Gigabit Ethernet ports
  • Four USB 2.0 ports
  • Two serial ports (COM1, COM2)
  • PS/2 keyboard/mouse connection
• Expansion Options:
  • One PCI-X PMC site
  • Board-to-board connector for PMC expansion
• Bus Interface:
  • VME 6U form factor
  • Tundra Universe II VME64 interface chip
• Supported Protocols: Modbus, Ethernet/IP, Profibus, DeviceNet, CANopen

Series

Features

• High-Performance Processing: Equipped with a powerful Intel Core 2 Duo processor for efficient data handling.
• Robust Communication: Multiple Ethernet and serial ports for reliable data transmission.
• Data Integrity: ECC memory to prevent data corruption.
• Flexible Configuration: Supports multiple programming languages and operating systems.
• Redundant Design: Ensures continuous operation even in the event of a primary controller failure.

Functions

• Real-Time Control: Ideal for applications requiring precise control and monitoring.
• Data Acquisition: Collects and processes large amounts of data in real-time.
• System Integration: Easily integrates into existing VMEbus systems.

Uses

• Industrial Automation: For precise control and monitoring in manufacturing plants.
• Process Control: In industries like petrochemical, power, and metallurgy.
• Energy Management: Monitors and controls power distribution systems.
• Water Treatment: Water quality monitoring and control systems.

Application Fields

• Manufacturing: Automobile, food & beverage industries.
• Energy: Power generation, transmission, and distribution.
• Chemical & Pharmaceutical: Chemical process control and pharmaceutical production.
• Water Treatment: Water quality monitoring and control systems.
• Transportation: Railway signal control, port automation

Product Description

Product Parameters

• Processor: 600 MHz Pentium-M microprocessor
• Memory: 512 MB user memory, 2 GB flash memory
• Operating Voltage: 24V DC
• Power Consumption: 5W (typical)
• Operating Temperature Range: -40°C to +85°C
• Dimensions: 233 mm x 167 mm x 30 mm
• Weight: Approximately 0.5 kg

Product Specifications

• Network Interfaces: Two Ethernet ports (10/100 Mbps), RS-232, RS-485
• Supported Protocols: Ethernet/IP, Modbus TCP/IP, Profibus, DeviceNet, CANopen
• I/O Capacity: Supports up to 256 I/O points
• Redundancy: Supports redundant CPU modules for high availability

Series

Features

• High-Performance Processing: Equipped with a 600 MHz Pentium-M processor for efficient data handling.
• Robust Communication: Multiple Ethernet and serial ports for reliable data transmission.
• Data Integrity: ECC memory to prevent data corruption.
• Flexible Configuration: Supports multiple programming languages (e.g., Ladder Logic, Structured Text, Function Block Diagram).
• Redundant Design: Ensures continuous operation even in the event of a primary controller failure.

Functions

• Real-Time Control: Ideal for applications requiring precise control and monitoring.
• Data Acquisition: Collects and processes large amounts of data in real-time.
• System Integration: Easily integrates into existing industrial control systems.

Uses

• Industrial Automation: For precise control and monitoring in manufacturing plants.
• Process Control: In industries like petrochemical, power, and metallurgy.
• Energy Management: Monitors and controls power distribution systems.
• Water Treatment: Water quality monitoring and control systems.

Application Fields

• Manufacturing: Automobile, food & beverage industries.
• Energy: Power generation, transmission, and distribution.
• Chemical & Pharmaceutical: Chemical process control and pharmaceutical production.
• Water Treatment: Water quality monitoring and control systems.
• Transportation: Railway signal control, port automation

Product Description

Product Parameters

• Processors: Dual Intel Pentium III, up to 1.26 GHz
• Memory: Up to 2 GB SDRAM with ECC (Error-Correcting Code)
• System Bus: 133 MHz
• Storage Interface: Ultra320 SCSI
• Network Interfaces: Two Fast Ethernet ports
• Communication Ports: Two serial ports
• Form Factor: Dual-slot VMEbus
• Operating Temperature Range: -40°C to +85°C
• Power Consumption: Approximately 100W

Product Specifications

• Chipset: ServerWorks LE with 133 MHz system bus
• Special Features: Designed for embedded applications, suitable for harsh industrial environments
• Mechanical Design: Robust construction for long-term reliability

Series

Features

• High-Performance Processing: Dual Pentium III processors for efficient data handling
• Robust Communication: Dual Ethernet ports for reliable data transmission
• Data Integrity: ECC memory to prevent data corruption
• Storage Capability: Ultra320 SCSI interface for high-speed data storage
• Versatile Applications: Suitable for industrial automation, aerospace, and scientific research

Functions

• Real-Time Control: Ideal for applications requiring precise control and monitoring
• Data Acquisition: Collects and processes large amounts of data in real-time
• System Integration: Easily integrates into existing VMEbus systems

Uses

• Industrial Automation: For precise control and monitoring in manufacturing plants
• Aerospace: For embedded systems in aircraft and spacecraft
• Scientific Research: For data acquisition and processing in research facilities

Application Fields

• Manufacturing: Automobile, food & beverage industries
• Energy: Power generation, transmission, and distribution
• Chemical & Pharmaceutical: Chemical process control and pharmaceutical production
• Water Treatment: Water quality monitoring and control systems
• Transportation: Railway signal control, port automation

Product Description

Product Parameters

• Model Number: RS-FS-9001 362A1052P004
• Brand: GE (General Electric)
• Type: Flame Detector
• Detection Technology: UV and IR (Ultraviolet and Infrared)
• Operating Voltage: 220V AC
• Power Consumption: 100W
• Operating Temperature Range: -40°C to +85°C
• Storage Temperature Range: -20°C to +70°C
• Detection Range: Up to 30 feet (approximately 9 meters)
• Response Time: ≤5 seconds
• Dimensions: 8.7 inches (221 mm) x 4.3 inches (109 mm) x 4.3 inches (109 mm)
• Weight: 3.5 pounds (approximately 1.6 kilograms)
• Protection Rating: IP65

Product Specifications

• Sensing Technology: Utilizes UV and IR sensing for high sensitivity and reliability.
• Certifications: Class I Division 2, Zone 2 hazardous area certifications for North America, ATEX, and IECEx.
• Mounting Options: Suitable for DIN rail or panel mounting.

Series

Features

• High Sensitivity: Capable of detecting even small flames and combustion phenomena.
• Fast Response: Rapid detection and alarm triggering within 5 seconds of flame detection.
• Robust Design: Built with high-quality materials to ensure long-term stability and minimal downtime.
• Versatile Communication: Supports multiple communication protocols for seamless integration into industrial control systems.
• Easy Installation: Designed for easy installation and integration with other modules or circuit boards.

Functions

• Flame Detection: Monitors combustion processes to ensure safety and prevent equipment damage.
• Alarm Triggering: Automatically triggers alarms in case of flame failure or abnormal conditions.

Uses

• Power Plants: Monitoring combustion in boilers and turbines.
• Industrial Heating: Ensuring safe operation of high-temperature heating equipment.
• Energy and Petrochemical Industries: Detecting flames in gas turbines, refineries, and chemical plants.

Application Fields

• Energy: Power generation and distribution.
• Petrochemical: Refineries and chemical processing plants.
• Metallurgy: Steel and metal production facilities.
• Other Industrial Applications: Any environment requiring reliable flame detection

Product Description

Product Parameters

• Input Voltage: 24V DC
• Output: 16 discrete outputs, 8 analog outputs
• Processor: 32-bit
• Memory: 64 MB
• Communication: Ethernet, RS-232, RS-485
• Operating Temperature: -25°C to +65°C
• Power Supply: 110-240V AC
• Form Factor: 6.25 x 5 inches
• Weight: Not specified

Product Specifications

• Terminal Connectors: 8 terminal connectors marked E1 to E8
• Additional Connectors: 8-pin connector and a thin film capacitor installed on the board
• Mounting: Four holes in the corners align with the mounting holes on the bracket
• Cooling: Requires a clean air source to keep components within the allowable temperature range
• Safety Features: Overtemperature detection to prevent component damage and fires

Series

Features

• High-Precision Control: Suitable for precise control of various motors and devices
• LAN Communication: Built-in LAN communication for efficient data transfer and remote monitoring
• Buffer Protection: Provides buffering and protection for inverters
• Robust Design: High-temperature tolerance, good electrical insulation, and high mechanical strength

Functions

• Voltage Suppression: Limits voltage spikes to protect the system
• Cooling Management: Ensures proper cooling to maintain component temperatures within safe limits
• System Protection: Detects overtemperature conditions to prevent damage and fires

Uses

• Turbine Control Systems: For precise control and monitoring of gas, steam, and wind turbines
• Industrial Automation: Ensures reliable operation in harsh industrial environments
• Power Generation: Monitors and controls power distribution systems
• Water Treatment: Water quality monitoring and control systems

Application Fields

• Manufacturing: Automobile, food & beverage industries
• Energy: Power generation, transmission, and distribution
• Chemical & Pharmaceutical: Chemical process control and pharmaceutical production
• Water Treatment: Water quality monitoring and control systems
• Transportation: Railway signal control, port automation

Product Description

Product Parameters

• Processor: Intel Pentium III, up to 1.26 GHz
• Memory: Up to 512 MB SDRAM
• Graphics Controller: Integrated AGP graphics via Intel 815E chipset, supporting up to 1600×1200 resolution
• Network Interfaces: Dual 10BaseT/100BaseTX Ethernet controllers
• Bus Standard: VMEbus
• Operating Systems Supported: Windows 2000, VxWorks, Solaris, QNX, LynxOS, Linux
• Form Factor: Single-slot VME Eurocard
• Weight: 1.30 lbs

Product Specifications

• CPU: Intel Pentium III processor, up to 1.26 GHz
• Chipset: Intel 815E with built-in AGP graphics
• Memory Type: PC133 SDRAM
• Graphics: Integrated AGP graphics, supporting up to 1600×1200 resolution
• Networking: Dual Ethernet controllers, supporting 10BaseT and 100BaseTX
• I/O Interfaces:
  • 2 x USB ports
  • IDE support for hard drives
  • Front panel reset switch and FAIL LED indicator
• Expansion: PMC site for custom modules
• BIOS: Reprogrammable flash memory, including system BIOS and video BIOS
• Mechanical: Standard VME single-board computer form factor

Series

Features

• High-Performance Processing: Equipped with a powerful Pentium III processor.
• Robust I/O Capabilities: Dual Ethernet controllers, USB ports, and IDE support.
• Flexible OS Support: Supports multiple operating systems, including Windows 2000, VxWorks, and Linux.
• Rugged Design: Suitable for harsh industrial environments.
• VME Compatibility: Easily integrates into existing VME systems.

Functions

• Real-Time Control: Suitable for time-sensitive industrial control applications.
• Data Acquisition: Collects and processes data from various sensors and devices.
• Communication: Facilitates data exchange through dual Ethernet interfaces.
• System Monitoring: Provides real-time monitoring and diagnostics through front panel indicators.

Uses

• Industrial Automation: For precise control and monitoring in manufacturing plants.
• Data Acquisition Systems: For real-time data collection and processing.
• Communication Equipment: For managing communication networks.
• Aerospace: For flight control systems and experimental equipment.
• Medical Equipment: For diagnostic and treatment applications.

Application Fields

• Manufacturing: Automobile, food & beverage industries.
• Energy: Power generation, transmission, and distribution.
• Chemical & Pharmaceutical: Chemical process control and pharmaceutical production.
• Water Treatment: Water quality monitoring and control systems.
• Transportation: Railway signal control, port automation

Product Description

Product Parameters

• Dimensions: 14.8 cm (L) x 10.3 cm (W) x 3.2 cm (H)
• Weight: 0.24 kg
• Components: Transformers, inductors, power supplies, fuses, varistors, resistors, capacitors, connectors, heat sinks, and LEDs
• Connectors: Stab-on connectors, plug connectors, header connectors
• LED Indicators: For real-time monitoring

Product Specifications

• Series: Mark VIe
• Function: Power regulation and protection for turbine control systems
• Design: Robust components for reliable operation in harsh environments
• Cooling: Transistors positioned near heat sinks for efficient cooling

Series

Features

• High-Precision Power Regulation: Ensures stable power supply for critical control applications.
• Robust Design: Built with high-quality components for durability and reliability.
• Real-Time Monitoring: LED indicators provide instant feedback on operational status.
• Efficient Cooling: Transistors are positioned near heat sinks to prevent overheating.

Functions

• Power Regulation: Provides stable power to the control system.
• Protection: Monitors and protects against overvoltage, overcurrent, and other abnormal conditions.
• Real-Time Monitoring: LED indicators for immediate status feedback.

Uses

• Turbine Control Systems: For precise control and monitoring of gas and steam turbines.
• Industrial Automation: Ensures reliable operation in harsh industrial environments.

Application Fields

• Power Generation: For control and monitoring of turbines in power plants.
• Industrial Automation: For reliable power supply in manufacturing and process control

Product Description

Product Parameters

• Processor: 96 MHz 32-bit floating-point processor
• Memory:
  • 1 MByte of battery-backed Fast CMOS RAM
  • 256K non-volatile flash memory for optional user data storage
• I/O Support: Up to 12K inputs and outputs (any mix), 8K analog I/O
• Serial Ports:
  • Port 1: RS-232 compatible
  • Port 2: RS-485 compatible (optocoupler isolated)
  • Port 3: RS-485 compatible (not isolated)
• Power Requirements: +5 VDC at 3.1 Amps nominal
• Operating Temperature: 0 to 60°C (32°F to 140°F); 0 to 50°C (32°F to 122°F) without forced air
• Battery Life: Up to 6 months without power (with CPU battery)

Product Specifications

• Form Factor: Single-slot design for compact installation
• Communication: VME C.1 standard format for seamless communication with smart option modules
• Programming: Configured and programmed using MS-DOS or Windows-based software
• Diagnostics: Onboard status LEDs and software diagnostics for real-time monitoring

Series

Features

• High-Speed Processing: Performs floating-point calculations every 0.4 microseconds.
• Flexible Configuration: Supports a wide range of I/O modules and coprocessors.
• Robust Communication: Equipped with three serial ports for versatile data exchange.
• Memory Protection: Battery-backed RAM ensures data retention during power loss.
• Easy Integration: Compatible with the entire IC697 family of modules.

Functions

• Real-Time Control: Handles high-speed, time-sensitive control tasks.
• Data Exchange: Communicates with external devices via serial ports.
• System Diagnostics: Provides real-time status feedback through LEDs and software.

Uses

• Industrial Automation: Suitable for manufacturing, energy management, and process control.
• High-Speed Control: Ideal for applications requiring precise and rapid control.
• System Integration: Easily integrates into new or existing control systems.

Application Fields

• Manufacturing: For precise control and monitoring in production lines.
• Energy Management: Monitors and controls power distribution systems.
• Process Control: Used in chemical, water treatment, and oil & gas industries
