​​Description:​​

The​​Beckhoff KL2134​​is a 4-channel digital output module designed for Beckhoff’s Bus Terminal system.This compact I/O module provides reliable 24V DC switching capability for actuators,relays,and indicators in industrial automation applications.With its robust design and seamless integration into EtherCAT systems,the​​KL2134​​offers efficient control solution for various automation tasks.

​​Application Scenarios:​​

In a packaging machine control system,multiple​​Beckhoff KL2134​​modules control solenoid valves for product sorting and rejection mechanisms.The modules’fast switching capability enables precise timing control,allowing the system to handle 120 packages per minute with accurate sorting based on quality inspection results.The​​KL2134​​modules’reliability has reduced machine downtime by 30%compared to previous solutions,contributing to increased production efficiency.

​​Parameter:​​

Main Parameters

Value/Description

​​Product Model​​

​​KL2134​​

​​Manufacturer​​

Beckhoff Automation

​​Product Category​​

Digital Output Module

​​Channels​​

4 channels

​​Output Type​​

24V DC transistor

​​Output Current​​

0.5A per channel

​​Short-Circuit Protection​​

Yes,electronic

​​Overload Protection​​

Yes

​​Response Time​​

<100μs

​​EtherCAT Cycle Time​​

<100μs

​​Electrical Isolation​​

500V(field to bus)

​​Power Supply​​

24V DC via power contacts

​​Operating Temperature​​

-25°C to+60°C

​​Storage Temperature​​

-40°C to+85°C

​​Connection​​

2-wire,screw terminal

​​Status Indicators​​

LED per channel

​​Width​​

12 mm

​​Technical Principles and Innovative Values:​​

The​​Beckhoff KL2134​​incorporates advanced features that enhance its performance in industrial applications:

​​High-Speed Switching:​​With response times under 100 microseconds,the​​KL2134​​enables precise control of fast-acting actuators and processes,making it suitable for high-speed automation applications.

​​Integrated Protection:​​The module features comprehensive electronic protection against short circuits and overloads,ensuring reliable operation and preventing damage to connected equipment.

​​Seamless EtherCAT Integration:​​As part of Beckhoff’s EtherCAT system,the​​KL2134​​benefits from deterministic communication and precise synchronization with other system components.

​​Application Cases and Industry Value:​​

​​Case Study:Automotive Assembly Line​​An automotive manufacturer implemented​​Beckhoff KL2134​​modules in their door panel assembly stations.The modules control pneumatic actuators for component positioning and clamping operations.The system’s reliability and fast response time have improved cycle times by 15%while reducing maintenance requirements.The modular design allowed for easy expansion when production volumes increased.

​​Related Product Combination Solutions:​​

The​​Beckhoff KL2134​​works seamlessly with these system components:

​​EK1100:​​EtherCAT Coupler for system integration

​​KL2114:​​Digital input module for sensor signals

​​KL3022:​​Analog output module for analog actuators

​​EL9410:​​Power supply terminal for system power

​​TwinCAT:​​Control software for programming and configuration

​​Installation,Maintenance,and Full-Cycle Support:​​

Installation and Maintenance:The​​Beckhoff KL2134​​modules install easily on standard DIN rails and connect via the Bus Terminal system.Regular maintenance includes checking terminal tightness and monitoring LED status indicators.The modular design allows for quick replacement if necessary.

Full-Cycle Support:Our technical team provides comprehensive support for​​KL2134​​integration,from system design to troubleshooting.We offer genuine Beckhoff components and expert guidance on system configuration and optimization.

Beckhoff KL2134
