Description​​

The B&R​​3IF260.60-1​​is a high-density digital input module designed for the X20 system,providing reliable signal acquisition for industrial automation applications.This compact module offers 32 digital input channels with advanced diagnostics,ensuring precise monitoring and control in demanding industrial environments.With its robust construction and flexible configuration options,it delivers exceptional performance for machine automation and process control systems.

Input Channels:32 points

Voltage Rating:24V DC

Isolation:500V AC

Diagnostics:Channel-level monitoring

​​Application Scenarios​​

In a high-speed packaging machine,the B&R​​3IF260.60-1​​module monitors sensor inputs from photoelectric detectors,proximity switches,and safety interlocks.When a product misalignment occurs,the module instantly detects the sensor state change and transmits the signal to the controller,triggering automatic correction within milliseconds.The module’s high channel density reduces cabinet space requirements by 40%compared to conventional I/O solutions,while its diagnostic capabilities enable predictive maintenance.

​​Parameter​​

Parameter

Specification

Product Model

​​3IF260.60-1​​

Manufacturer

B&R(Bernecker+Rainer)

Product Category

Digital Input Module

Compatible System

X20 System

Input Channels

32 points

Input Voltage

24V DC(15-30V DC)

Input Current

3-5 mA per point

Response Time

<1 ms

Isolation Voltage

500V AC

Power Consumption

4W typical

Connection Type

Spring-loaded terminals

Diagnostics

Channel-level short-circuit detection

Operating Temperature

0°C to+60°C

Storage Temperature

-25°C to+85°C

Protection Rating

IP20

Certifications

UL,CE,cULus

​​Technical Principles and Innovative Values​​

The B&R​​3IF260.60-1​​incorporates advanced signal processing technology with several innovative features:

Innovation Point 1:High-density channel design with individual diagnostics provides precise fault detection at the channel level,enabling quick identification of field wiring issues without affecting other channels’operation.

Innovation Point 2:Advanced filtering technology ensures reliable signal acquisition in electrically noisy industrial environments,minimizing false triggers and ensuring accurate machine control.

Innovation Point 3:Integrated temperature monitoring and overload protection prevent module damage under adverse conditions,extending service life and reducing maintenance requirements.

​​Application Cases and Industry Value​​

Case 1:An automotive assembly line implemented​​3IF260.60-1​​modules for robotic cell monitoring.The modules’reliability contributed to achieving 99.95%operational availability,with zero production stoppages attributed to I/O system failures over two years of continuous operation.

Case 2:In a pharmaceutical packaging facility,​​3IF260.60-1​​modules provided reliable monitoring of safety interlocks and machine status signals.The high channel density reduced cabinet space requirements by 35%while improving maintenance efficiency through advanced diagnostics.

​​Related Product Combination Solutions​​

​​B&R X20 CPU Modules​​:System processing core

​​B&R 3IF262.60-1​​Digital Output Module:Complementary output control

​​B&R 3AI462.60-1​​Analog Input Module:Precision measurement

​​B&R X20 Power Supply​​:System power distribution

​​B&R Automation Studio​​:Programming and configuration software

​​Installation,Maintenance,and Full-Cycle Support​​

Installation:The​​3IF260.60-1​​module installs on the X20 bus baseplate using the quick-lock mechanism.Ensure proper module sequencing and bus connection.Use ferrules on stranded wires for reliable spring terminal connections.

Maintenance:Regular diagnostic monitoring through Automation Studio software enables predictive maintenance.Perform periodic inspection of terminal connections and module status indicators.Update firmware during planned maintenance windows.

Support:Comprehensive technical support includes configuration assistance,troubleshooting guidance,and lifecycle management services.Our team provides expert support for system integration,commissioning,and ongoing maintenance.
