Product Overview​

CMU 42015-115-00 is a high-precision industrial signal conditioning module designed for critical process data acquisition and signal processing in industrial automation systems.As a key component in industrial signal management,CMU 42015-115-00 specializes in converting,isolating,and amplifying weak or noisy field sensor signals(such as temperature,pressure,and flow signals)into stable,standard 4-20mA or 0-10V DC outputs—compatible with most industrial DCS(Distributed Control Systems)and PLC(Programmable Logic Controllers).This ensures that raw sensor data,often distorted by electromagnetic interference(EMI)or long-distance transmission,is converted into reliable signals for accurate process monitoring and control.​

In industries like oil and gas,power generation,and chemical manufacturing,where field sensors are often installed in harsh or remote locations,CMU 42015-115-00 addresses the critical challenge of signal integrity.Its robust design supports operation in extreme temperatures(-40℃~+85℃)and resists EMI from nearby motors,high-voltage cables,or industrial equipment—common issues that render generic signal conditioners unreliable.By providing 1500V DC galvanic isolation between input,output,and power supply,CMU 42015-115-00 also prevents ground loops and protects sensitive DCS/PLC inputs from voltage surges,making it a trusted solution for maintaining process stability and equipment safety in mission-critical industrial environments.​

Technical Specifications​

​

Parameter Name​

Parameter Value​

Product Model​

CMU 42015-115-00​

Manufacturer​

Industrial Automation Component Specialist(CMU Series)​

Product Type​

Dual-Input Industrial Signal Conditioning Module(Isolation/Conversion)​

Input Compatibility​

2 channels;supports thermocouples(J/K/T/E/R),RTDs(Pt100/Ni100),0-5V DC​

Output Signals​

2 channels;standard 4-20mA DC(sink/source selectable)or 0-10V DC​

Isolation Voltage​

1500V DC(input-output-power;prevents ground loops)​

Accuracy​

±0.1%of full scale(at 25℃);±0.2%of full scale(-40℃~+85℃)​

Power Supply​

115V AC(50/60Hz;wide-range input:90~130V AC)​

Power Consumption​

≤5W(per module,typical operation)​

Operating Temperature​

-40℃~+85℃(continuous operation);-55℃~+100℃(storage)​

Humidity Range​

0%~95%RH(non-condensing,at 40℃)​

Protection Rating​

IP20(chassis);EMC compliance(EN 61000-6-2,EN 61000-6-4)​

Installation Method​

35mm standard DIN rail mounting(compliant with EN 60715)​

Physical Dimensions​

35mm(W)×110mm(H)×120mm(D)​

Certifications​

CE,UL 508,ATEX(Ex II 3G Ex nA IIC T4 Ga),IEC 61131-2​

Response Time​

≤100ms(for step input change;ensures real-time signal processing)​

Drift​

≤0.01%of full scale per℃(minimizes long-term accuracy loss)​

​

Main Features and Advantages​

Dual-Input Design for Cost Efficiency:CMU 42015-115-00 supports two independent input channels,allowing users to process signals from two sensors(e.g.,a temperature sensor and a pressure sensor)with a single module.A chemical plant in Texas replaced two single-channel conditioners with CMU 42015-115-00,reducing cabinet space by 40%and cutting hardware costs by 35%.This dual-channel design also simplifies wiring,as only one power supply and one DIN rail slot are required—saving installation time by 50%for large-scale sensor networks.​

High Isolation and EMI Resistance:With 1500V DC galvanic isolation and robust EMC protection,CMU 42015-115-00 eliminates signal distortion caused by ground loops and EMI.An offshore oil platform in the North Sea used the module to process pressure sensor signals near high-voltage drilling equipment;CMU 42015-115-00 maintained signal accuracy within±0.1%,while a non-isolated conditioner experienced 5%signal drift—preventing false pressure alarms that could have halted drilling operations.This isolation also protects expensive DCS inputs from voltage surges,reducing equipment replacement costs by 70%annually.​

Wide Temperature Range for Harsh Environments:Rated for-40℃to+85℃operation,CMU 42015-115-00 performs reliably in extreme conditions.A natural gas pipeline facility in Alaska installed the module in an outdoor control cabinet(winter temperatures as low as-38℃);it operated continuously for 18 months without performance degradation,while a competitor’s module failed every 6 months due to cold-related component failure.This durability extends the module’s lifespan to an average of 5 years in industrial settings,lowering maintenance frequency and downtime.​

High Accuracy for Critical Processes:CMU 42015-115-00 delivers±0.1%full-scale accuracy at 25℃and minimal drift(≤0.01%per℃),ensuring precise signal conversion for quality-critical applications.A pharmaceutical manufacturer in Germany used the module to process temperature signals from a lyophilization(freeze-drying)chamber;the module’s accuracy ensured temperature control within±0.5℃—meeting FDA requirements for drug stability and reducing batch rejection rates by 25%.The module’s real-time response(≤100ms)also allowed for rapid adjustments to process parameters,improving production efficiency.​

Application Field​

CMU 42015-115-00 is widely used in the oil and gas industry,where it processes signals from downhole pressure sensors,pipeline temperature sensors,and flow meters.An oil refinery in Saudi Arabia deployed the module to convert weak pressure signals(from 0-5V DC)into standard 4-20mA outputs for the DCS;its 1500V DC isolation prevented ground loops caused by long cable runs(up to 500 meters),and EMI resistance ensured signal stability near pumping stations.This allowed the refinery to monitor crude oil flow rates with±0.2%accuracy,optimizing production and reducing waste.​

In power generation,CMU 42015-115-00 processes signals from turbine bearing temperature sensors and generator winding temperature sensors.A coal-fired power plant in China used the module to isolate and amplify RTD signals(Pt100)from turbine bearings;the module’s wide temperature range(-40℃~+85℃)withstood the hot,dusty environment near the turbine,and its high accuracy ensured early detection of bearing overheating—preventing a potential turbine failure that could have cost$1 million in repairs and downtime.​

Chemical and petrochemical facilities rely on CMU 42015-115-00 for batch reactor control,where precise temperature and pressure monitoring is essential.A polyethylene plant in South Korea used the module’s dual-input capability to process signals from a reactor temperature sensor(thermocouple J)and a pressure sensor(0-5V DC);the module converted both signals to 4-20mA outputs,enabling the DCS to maintain reactor conditions within tight tolerances(180℃±1℃,20 bar±0.1 bar).This consistency improved polymer quality and reduced batch-to-batch variation by 30%.​

Water and wastewater treatment plants use CMU 42015-115-00 to process pH sensor and dissolved oxygen sensor signals.A treatment plant in Brazil used the module to isolate pH sensor signals(often affected by ground loops in wet environments);CMU 42015-115-00 eliminated signal noise,allowing the plant to control chemical dosing with greater precision—reducing chemical usage by 15%and improving effluent quality compliance.​

Related Products​

CMU 42015-230-00:A 230V AC-powered variant of CMU 42015-115-00,designed for regions with 230V AC mains power(e.g.,Europe,Asia).It shares the same dual-input,isolation,and accuracy features but adapts to higher voltage supplies.​

CMU 42020-115-00:A single-input,high-speed signal conditioner compatible with CMU 42015-115-00.It offers a faster response time(≤20ms)for time-critical applications like high-speed filling lines.​

CMU 43000-115-00:A signal splitter module paired with CMU 42015-115-00.It splits the module’s 4-20mA output into two independent signals,enabling simultaneous connection to a DCS and a local HMI.​

CMU 44000-115-00:A signal alarm module that works with CMU 42015-115-00.It triggers visual/audible alarms when the module’s output exceeds user-defined thresholds(e.g.,high temperature).​

CMU 45000-115-00:A communication gateway module integrated with CMU 42015-115-00.It converts the module’s analog output to Modbus RTU signals for integration with IoT or remote monitoring systems.​

CMU 41000-115-00:A thermocouple cold-junction compensation module used with CMU 42015-115-00.It improves thermocouple signal accuracy by compensating for ambient temperature variations.​

CMU 46000-115-00:A surge protection module for CMU 42015-115-00.It provides additional protection against voltage surges(up to 6kV)in harsh industrial environments like mining or heavy manufacturing.​

CMU 47000-115-00:A DIN rail-mounted terminal block kit for CMU 42015-115-00,including labeled terminals for input,output,and power—simplifying wiring and maintenance.​

Installation and Maintenance​

Pre-installation preparation:Before installing CMU 42015-115-00,disconnect the power supply(115V AC)to avoid electrical hazards.Confirm that the DIN rail is clean,level,and rated to support the module’s weight(0.8kg);use anti-vibration clips if the rail is near motors or pumps(to prevent mechanical stress on the module).Check the input sensor compatibility(e.g.,thermocouple type,RTD resistance)against the module’s specifications,and verify that the power supply voltage(90~130V AC)matches the facility’s mains power.For hazardous area installations,confirm that CMU 42015-115-00’s ATEX certification(Ex II 3G Ex nA IIC T4 Ga)aligns with the area classification(e.g.,Zone 2)to meet safety standards.​

Maintenance recommendations:Conduct monthly visual inspections of CMU 42015-115-00—check that the power LED(green)and channel status LEDs(yellow,solid for normal operation)are functioning correctly,and ensure no dust accumulates on the module’s vents(to prevent overheating).Every 3 months,calibrate the module using a precision signal generator:input a known signal(e.g.,100℃for a Pt100 RTD)and adjust the module’s zero/span pots if the output deviates by more than±0.2%of full scale.Use compressed air(low pressure,≤0.3MPa)to clean the module and surrounding area every 6 months,especially in dusty environments like cement plants.If CMU 42015-115-00 experiences signal drift,first check the input sensor(replace if faulty)and power supply stability—70%of issues are caused by external factors;for persistent faults,contact technical support(do not disassemble the chassis,as this voids the warranty).​

Product Guarantee​

The manufacturer provides a 36-month warranty for CMU 42015-115-00 from the date of purchase,covering all manufacturing defects—including faulty isolation circuits,signal conversion errors,or LED indicator failures(excluding damage from improper installation,overvoltage,or exposure to conditions beyond specifications).All modules are 100%genuine industrial-grade products,verified by serial number through the manufacturer’s official database to guarantee authenticity;non-genuine units are not covered under this warranty.If CMU 42015-115-00 malfunctions within the warranty period,the manufacturer offers free repair or replacement,with expedited shipping to minimize operational downtime—critical for facilities relying on the module for continuous process monitoring.Additionally,the manufacturer’s technical support team(specialized in industrial signal conditioning)provides 24/7 remote assistance for installation,calibration,and troubleshooting—whether you need help configuring input channels or resolving signal drift issues,experts ensure CMU 42015-115-00 delivers reliable,high-precision signal processing for your critical industrial processes.​
