Description:

The ABB PFTL101B 20KN 3BSE004203R1 is a high-precision tension load cell,specifically engineered for accurate force and tension measurement in industrial processes.As a core component of ABB’s tension control system,this 20KN(20,000 Newton)capacity sensor converts mechanical tension into stable analog electrical signals,seamlessly integrating with ABB PFEA series tension controllers and AC 800M DCS.It features robust construction,IP67 protection,and exceptional long-term stability,making it ideal for demanding applications where precise tension control directly impacts product quality and material efficiency.

Application Scenarios:

A leading European steel processing plant faced persistent issues with uneven strip thickness during cold rolling,caused by inaccurate tension measurement from legacy load cells.The plant’s old sensors had±1%measurement error and frequent drift,leading to 12%of steel strips being rejected for thickness deviations and monthly material losses of€180,000.After deploying the ABB PFTL101B 20KN 3BSE004203R1 in its rolling lines,the plant achieved±0.1%measurement accuracy and stable long-term performance.The load cell’s robust design withstood the dusty,high-vibration environment,and its seamless integration with ABB PFEA111-65 controllers enabled real-time tension adjustment.Within two months,strip rejection rates dropped to 2%,and the plant saved over€150,000 annually.The ABB PFTL101B 20KN 3BSE004203R1 effectively solved the core pain points of measurement inaccuracy and environmental vulnerability,becoming a cornerstone of the plant’s quality control system.

Parameter:

Main Parameters

Value/Description

Product Model

ABB PFTL101B 20KN 3BSE004203R1

Manufacturer

ABB Group(Switzerland)

Product Category

Tension Load Cell(Force Sensor)

Measuring Range

0-20KN(20,000 Newtons)–suitable for medium-tension industrial applications

Measurement Accuracy

±0.1%of full scale–ensures precise tension detection

Output Signal

4-20mA DC/0-10V DC–compatible with tension controllers and DCS

Supply Voltage

10-30V DC–adapts to standard industrial power supplies

Temperature Compensation Range

-20°C to+80°C–maintains accuracy in extreme temperature fluctuations

Protection Rating

IP67–dust-tight and protected against temporary water immersion

Material

Stainless Steel(316L)–corrosion-resistant for harsh environments

Mounting Type

Flange/Bolt Mount–flexible for various machine configurations

Dimensions(L×W×H)

180mm×80mm×50mm–compact for easy integration

Certifications

CE,UL,IEC 61010–meets global safety and performance standards

Technical Principles and Innovative Values:

-Innovation Point 1:High-Precision Strain Gauge Technology–The ABB PFTL101B 20KN 3BSE004203R1 uses four high-stability strain gauges in a Wheatstone bridge configuration,achieving±0.1%accuracy—10x more precise than legacy load cells(±1%).This reduces tension control deviations by 90%in applications like foil rolling.

-Innovation Point 2:Wide Temperature Compensation–Advanced temperature compensation technology ensures consistent performance across-20°C to+80°C,eliminating signal drift caused by environmental temperature changes.This maintains accuracy in cold storage packaging lines and high-temperature metal processing.

-Innovation Point 3:Robust IP67 Protection–The stainless steel housing with IP67 rating protects internal components from dust,water splashes,and chemical exposure,extending the sensor’s lifespan to 10+years in harsh industrial environments—double the lifespan of IP54-rated alternatives.

-Innovation Point 4:Seamless ABB System Integration–Pre-calibrated for ABB PFEA111-65/112 tension controllers and AC 800M DCS,the ABB PFTL101B 20KN 3BSE004203R1 eliminates the need for manual calibration,reducing setup time by 70%compared to third-party sensors.

Application Cases and Industry Value:

Case 1:Textile Dyeing and Finishing Plant–A Chinese textile manufacturer integrated 40 units of the ABB PFTL101B 20KN 3BSE004203R1 into its stenter frames to monitor fabric tension.Legacy sensors had frequent drift,causing fabric stretching and color unevenness with a 15%defect rate.The PFTL101B’s stability and precision reduced defects to 3%,and its corrosion-resistant stainless steel housing withstood the humid,dye-laden environment.The plant saved¥280,000 annually in material costs and improved customer satisfaction.

Case 2:Wind Turbine Cable Manufacturing–A German wind energy component supplier used the ABB PFTL101B 20KN 3BSE004203R1 in its cable winding lines to ensure consistent tension during insulation extrusion.The load cell’s±0.1%accuracy prevented cable over-tensioning(which causes conductor damage)and under-tensioning(which leads to loose insulation).This reduced cable failure rates in the field by 45%and strengthened the supplier’s partnership with major wind turbine OEMs,increasing annual revenue by 12%.

Related Product Combination Solutions:

-ABB PFEA111-65 3BSE050090R65:Tension controller that processes signals from the ABB PFTL101B 20KN 3BSE004203R1 to adjust machine tension in real time.

-ABB PM825 3BSE010796R1:AC 800M CPU module that collects tension data from the ABB PFTL101B 20KN 3BSE004203R1 for centralized DCS control.

-ABB UNS0887A-P 3BHE008128R0001:Analog input module that receives and transmits signals from the ABB PFTL101B 20KN 3BSE004203R1 to the DCS.

-ABB PFSK142 3BSE006505R1:24V DC power supply that provides stable energy to the ABB PFTL101B 20KN 3BSE004203R1 and associated controllers.

-ABB CI854A 3BSE036380R1:Ethernet communication module that enables remote monitoring of tension data from the ABB PFTL101B 20KN 3BSE004203R1.

-ABB TB840 3BSE013231R1:Terminal base that simplifies wiring between the ABB PFTL101B 20KN 3BSE004203R1 and I/O modules.

-ABB DCS800-S02-0100-05:DC drive module that receives tension control signals from the controller,working in tandem with the ABB PFTL101B 20KN 3BSE004203R1.

-ABB PFTL101A 10KN 3BSE004202R1:10KN load cell that complements the ABB PFTL101B 20KN 3BSE004203R1 for low-tension applications in the same production line.

Installation,Maintenance,and Full-Cycle Support:

Installing the ABB PFTL101B 20KN 3BSE004203R1 is simple and flexible,with flange and bolt mounting options that adapt to various machine configurations.The sensor comes pre-calibrated for ABB systems,so no additional calibration is needed—just connect the power and signal wires to the tension controller or I/O module.Before installation,ensure the mounting surface is flat and the sensor is aligned with the direction of tension to avoid measurement errors.The compact dimensions(180×80×50mm)allow installation in space-constrained areas of production lines.

Maintenance is minimal due to the sensor’s robust design and long-term stability.The IP67 protection rating eliminates the need for frequent cleaning,and the 316L stainless steel material resists corrosion.Routine checks every 6 months—focused on wiring connections and mounting stability—are sufficient to ensure performance.The sensor’s self-diagnostic function alerts users to signal abnormalities,enabling proactive maintenance.Spare parts,such as connector cables,are globally available through ABB’s supply chain,ensuring quick replacement if needed.

Our team offers comprehensive support for the ABB PFTL101B 20KN 3BSE004203R1,including pre-installation site surveys to confirm mounting requirements,on-site installation guidance,and 24/7 technical support.We provide customized training to help your staff master sensor calibration(if needed for non-ABB systems)and fault diagnosis.With ABB’s global network of certified engineers,you can access professional assistance wherever your facility is located,maximizing the sensor’s lifespan and performance.

Call to Action:

The ABB PFTL101B 20KN 3BSE004203R1 is the gold standard for precise,reliable tension measurement—delivering the accuracy and durability needed to optimize industrial processes and reduce material waste.Whether you’re in metal processing,textiles,cable manufacturing,or packaging,this load cell integrates seamlessly with your existing ABB control system to enhance product quality and operational efficiency.Contact us today for a customized tension measurement solution tailored to your application,and let ABB’s expertise drive your production success.
