Product Overview
TheMarposs 886C202000represents a sophisticated electronic amplifier unit within Marposs’s comprehensive dimensional measurement system portfolio.This precision instrument serves as the signal processing and conditioning center for Marposs’s contact and non-contact measurement probes,converting minute mechanical displacements into precise electrical signals for dimensional evaluation.Designed for integration in industrial metrology applications,theMarposs 886C202000provides the critical link between measurement sensors and display/control systems,ensuring accurate and reliable dimensional data acquisition in manufacturing environments.
As a central component in Marposs’s gauging systems,theMarposs 886C202000features advanced electronic circuitry that amplifies,linearizes,and conditions signals from various Marposs measurement probes.The unit typically supports multiple input channels,allowing simultaneous monitoring of several measurement points with high resolution and stability.The robust construction of theMarposs 886C202000ensures reliable operation in production environments where electrical noise,temperature variations,and mechanical vibrations are present,making it suitable for both machine tool integration and standalone gauging stations.
The functionality of theMarposs 886C202000extends beyond basic signal amplification to include sophisticated features such as automatic calibration,temperature compensation,and programmable tolerance limits.These capabilities enable the amplifier to maintain measurement accuracy even under varying environmental conditions and provide immediate feedback for quality control decisions.The versatility of theMarposs 886C202000makes it suitable for a wide range of applications from automotive component manufacturing to precision machining,where dimensional accuracy directly impacts product quality and manufacturing efficiency.
Technical Specifications
Parameter Name
Parameter Value
Product Model
886C202000
Manufacturer
Marposs
Product Type
Gauging Amplifier
Input Channels
Single or dual channel(model dependent)
Input Signal
LVDT,inductive,or capacitive probe signals
Measurement Range
±1mm to±10mm(probe dependent)
Resolution
0.1 micron(typical)
Linearity
≤±0.5%of full scale
Output Signals
Analog voltage(0-10V),analog current(4-20mA),digital(RS-232/485)
Response Time
Adjustable,typically 1-10ms
Operating Voltage
100-240V AC,50/60Hz or 24V DC
Power Consumption
<15W
Operating Temperature
0°C to+50°C
Storage Temperature
-20°C to+70°C
Display
LED or LCD with tolerance indicators
Control Inputs
External reset,tolerance set,mode selection
Enclosure Rating
IP54(front panel)
Mounting
Panel mount or DIN rail
Dimensions
Approximately 96mm x 96mm x 100mm
Weight
Approximately 0.8kg
Main Features and Advantages
TheMarposs 886C202000offers significant advantages through its high-precision signal processing and versatile configuration capabilities.The amplifier achieves exceptional measurement resolution of 0.1 micron,ensuring accurate dimensional assessment even for the most demanding precision manufacturing applications.This precision capability of theMarposs 886C202000is crucial for applications requiring tight tolerance control,such as bearing manufacturing,fuel injection components,and transmission parts where dimensional accuracy directly impacts product performance and quality.
Operational flexibility is enhanced by the multiple input and output options incorporated in theMarposs 886C202000.The amplifier supports various Marposs probe technologies,allowing adaptation to different measurement requirements without changing the core electronics.The programmable tolerance limits with visual and electrical outputs enable immediate pass/fail determination,facilitating rapid quality decisions in production environments.The robust design of theMarposs 886C202000provides excellent immunity to electrical noise and environmental variations,ensuring stable performance in challenging industrial conditions.
User-friendly operation and integration capabilities are key benefits of theMarposs 886C202000design.The clear display with tolerance indicators provides immediate visual feedback,while the simple calibration procedures minimize setup time.The multiple output options enable seamless integration with various control systems,from simple relay logic to sophisticated CNC controls and data acquisition systems.These features make theMarposs 886C202000a versatile and efficient solution for diverse dimensional measurement applications in modern manufacturing facilities.
Application Field
TheMarposs 886C202000finds extensive application in precision manufacturing sectors requiring high-accuracy dimensional verification.In automotive component manufacturing,this gauging amplifier is used for critical part inspection including piston measurements,bearing bore sizing,and shaft diameter verification where micron-level accuracy is essential for performance and longevity.The reliability of theMarposs 886C202000makes it indispensable for in-process gauging applications on grinding machines,turning centers,and dedicated inspection stations where real-time measurement feedback enables adaptive machining and quality control.
Aerospace component manufacturing represents another significant application area for theMarposs 886C202000,particularly in the measurement of turbine blades,engine components,and landing gear parts where material integrity and dimensional precision are critical.The amplifier’s stability and resolution ensure consistent measurement results for complex geometries and challenging materials.TheMarposs 886C202000is particularly valuable in these applications where measurement reliability directly impacts safety and performance requirements.
Medical device manufacturing and precision engineering applications also benefit substantially from the capabilities of theMarposs 886C202000.In the production of surgical instruments,implants,and micro-components,the amplifier’s high resolution and stability enable precise dimensional verification without part damage.The adaptability of theMarposs 886C202000to various measurement setups,from standalone gauging stations to integrated machine tool applications,makes it a versatile solution for manufacturers across multiple precision industries.
Related Products
Marposs E9066 N Gauging Head:Precision measurement probe compatible with the amplifier
Marposs M10 MarCator:Digital display unit for measurement readout
Marposs P7 PanCator:Analog comparator for tolerance indication
Marposs Various Contact Tips:Selection of styli for different measurement applications
Marposs Mounting Accessories:Fixtures and brackets for system installation
Marposs Connection Cables:Specialized cabling for signal transmission
Marposs Calibration Masters:Precision artifacts for system calibration
Installation and Maintenance
Installation preparation:Before installing theMarposs 886C202000,verify compatibility with the existing measurement probes and ensure proper electrical supply specifications.Check the measurement environment for excessive vibration or electrical noise that could affect measurement accuracy.For theMarposs 886C202000,ensure adequate space for heat dissipation and accessibility for calibration and maintenance.
Maintenance recommendations:Regular maintenance for theMarposs 886C202000should include periodic calibration verification using master artifacts to ensure measurement accuracy.Keep the unit clean and free from dust accumulation,and inspect connections for security.For theMarposs 886C202000,regularly check the display and indicator functionality,and maintain records of calibration dates and results for quality assurance purposes.
Product Guarantee
We guarantee that everyMarposs 886C202000gauging amplifier supplied is a genuine Marposs product manufactured to the highest quality standards and compliant with all relevant technical specifications.Each unit undergoes rigorous testing to ensure reliable performance in precision measurement applications.Our technical support team provides comprehensive assistance for product selection,system integration,and application guidance,ensuring that your investment in theMarposs 886C202000delivers optimal measurement accuracy and reliability throughout its service life.
