GE CP238TA

Product Description

Product Parameters

• Voltage: 24V
• Output Frequency: 65Hz
• Weight: 1.3 kg
• Dimensions: 213x96mm
• Digital I/O Channels: 8
• Ethernet Interface: 10/100/1000BaseTX
• Bus Operation: Asynchronous master/auxiliary PCI bus operation

Product Specifications

• Form Factor: 6U CompactPCI
• PMC Slots: Dual PMC slots supporting 32/64-bit width and 33/66 MHz operation
• Hot-Swap Capability: Complete hot-swap register control with blue light indication
• Bus Architecture: Supports asynchronous operation of the main and auxiliary PCI buses

Series

Features

• Modular Design: Facilitates easy integration and expansion in CompactPCI systems.
• Hot-Swap Functionality: Allows safe removal or insertion without interrupting system operation.
• Network Connectivity: Provides seamless network connection through the Ethernet port.
• High Reliability: Suitable for harsh industrial environments.

Functions

• Data Acquisition and Signal Processing: Collects and processes data in industrial automation lines.
• Process Control: Real-time monitoring and control of industrial processes.
• Gas Turbine Control: Monitors combustion processes and generator output parameters.
• Emergency Power Supply: Serves as a reliable backup power control module.

Uses

• Power Generation: Controls combustion processes and adjusts output power in gas turbine generator sets.
• Industrial Automation: Manages industrial processes, power distribution, and energy production.
• District Heating: Controls combustion and hot water output.
• Emergency Power Supply: Provides reliable control for backup power systems.

Application Fields

• Power Generation Plants
• Industrial Automation
• District Heating Systems
• Emergency Power Systems
• Telecom and Data Centers

GE IC697ALG320

Product Description

Product Parameters

• Brand: GE Fanuc
• Series: Series 90-70
• Part Number: IC697ALG320
• Output Channels: 4
• Output Ranges:
  • Voltage: -10VDC to +10VDC
  • Current: 0.0 mA to 22.5 mA (default 4 to 20 mA)
• Resolution: 16-bit with 14-bit monotonicity
• Conversion Rate: 2 ms for all 4 channels
• Power Requirement: 1.66 Amps (8.3 watts) at +5 Volts
• Operating Temperature: 0°C to 60°C
• Dimensions: 100 mm x 150 mm x 60 mm
• Weight: 0.7 kg
• Certifications: CE, UL

Product Specifications

• Output Accuracy:
  • Voltage: Factory set at full scale = 10 volts ±2.5 millivolts
  • Current: Factory set at 4.0 mA ±5 µA and 20 mA ±5 µA
• Output Loading:
  • Voltage: Minimum 2000 ohms for resistive loads, maximum 1000 picofarads for capacitive load
  • Current: Up to 700 ohms for resistive loads, maximum 1.0 microfarad for capacitive loads, 250 milliHenry for inductive loads
• Temperature Coefficient:
  • Voltage: 25 PPM per °C
  • Current: 50 PPM per °C
• Calibration: Factory calibrated with data stored in EEPROM memory
• Short Circuit Protection: Continuous short circuit without harm, output returns to normal state once the fault is addressed

Series

Features

• High-Precision Output: 16-bit resolution with 14-bit monotonicity ensures accurate signal conversion.
• Fast Update Rate: 2 ms conversion rate for all channels supports real-time control applications.
• Flexible Configuration: Each output channel can be individually configured for voltage or current operation.
• Built-in Diagnostics: Features over-range, under-range, open-wire detection, and module health monitoring.
• Isolated Output Circuitry: Ensures reliable operation in noisy industrial environments.
• Hot-Swap Capability: Allows module replacement without shutting down the system.

Functions

• Signal Conversion: Converts digital signals from the PLC into analog output signals.
• Real-Time Control: Provides real-time control of actuators and other devices.
• System Integration: Integrates seamlessly with other Series 90-70 modules and systems.

Uses

• Power Generation: Controlling generator parameters such as voltage and current.
• Oil & Gas: Regulating valve positions and flow rates in pipelines.
• Manufacturing: Controlling temperature, pressure, and other process variables.
• Water/Wastewater Treatment: Managing chemical dosing and pump operations.

Application Fields

• Power Generation
• Oil & Gas
• Manufacturing
• Water/Wastewater Treatment
• Other Industrial Automation Applications

GE IC694CHS392

Product Description

Product Parameters

• Series: PACSystem RX3i
• Manufacturer: GE Fanuc (currently under Emerson Automation)
• Part Number: IC694CHS392
• Number of Slots: 10
• Maximum Cable Length: 50 feet (15 meters)
• Dimensions: 5.12 x 17.44 x 5.59 inches (H x W x D)
• Mounting: Panel mounting
• Power Supply Module: Required for local power to installed modules.

Product Specifications

• Backplane Support: High-Speed Serial Only
• Slot Assignment: I/O modules and option modules
• Expansion Slot: 25-pin D-shell female connector
• Hot Insertion and Removal: Not supported
• Internal Power Consumption: 150 mA at 5 VDC.

Series

Features

• High Flexibility: Supports a variety of I/O modules for expanded system capabilities.
• Long Distance Capability: Can be located up to 50 feet from the main CPU backplane.
• Robust Design: Suitable for industrial environments with panel mounting options.

Functions

• System Expansion: Increases the number of I/O modules that can be connected to the RX3i system.
• Module Integration: Allows for the integration of analog, discrete, and special-function modules.

Uses

Application Fields

• Industrial Automation: For expanding control systems in manufacturing plants.
• Process Control: In industries such as oil and gas, water treatment, and power generation.
• Other Applications: Any scenario where a PLC system requires additional I/O capacity

GE VMIVME-7700

Product Description

Product Parameters

• Processor: Intel Ultra Low Voltage Celeron 400 MHz or 650 MHz
• Memory: Up to 512 MB SDRAM
• Form Factor: 6U Eurocard
• Bus Interface: VME64
• Ethernet: Dual Ethernet controllers with 10/100BaseTX support
• Storage: Optional CompactFlash up to 1 GB
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +80°C
• Dimensions: 233 mm x 167 mm x 30 mm
• Weight: 1.2 kg

Product Specifications

• System Bus: 100 MHz
• I/O Ports:
  • Two high-performance 16550-compatible serial ports
  • Two USB ports
  • PS/2-style keyboard and mouse ports
• Expansion: One PMC expansion site
• Boot Options: Remote Ethernet booting, CompactFlash boot

Series

Features

• High Performance: Ultra-low voltage Celeron processor for efficient processing.
• Reliability: Designed for industrial environments with wide temperature ranges and passive cooling.
• Flexibility: Supports multiple boot options and expansion capabilities.
• Compatibility: Compatible with VME64 standard, ensuring interoperability with other VMEbus devices.

Functions

• System Control: Manages the overall operation of the control system.
• Data Processing: Analyzes and processes data from various sensors and devices.
• Communication: Facilitates data exchange with other VMEbus modules and devices.
• I/O Expansion: Connects to various peripherals for extended functionality.

Uses

• Industrial Automation: For data acquisition, control logic implementation, and equipment monitoring.
• Military and Aerospace: For embedded systems requiring high reliability and performance.
• Scientific Research: For data acquisition and analysis in experimental setups.

Application Fields

• Industrial Automation
• Military and Aerospace
• Scientific Research
• Medical Equipment
• Other Embedded Systems

GE SR489-P5-HI-A20-E

Product Description

Product Parameters

• Phase Current Input: 5A phase CT secondary
• Control Power: 90-300VDC and 70-265VAC at 48-62 Hz
• Analog Output: 4 to 20 mA
• Digital Inputs: 7 assignable digital inputs
• Communication Interfaces: RS232, RS485, 10Mbps copper Ethernet
• Protocols Supported: Modbus RTU, Modbus TCP/IP, DNP 3.0

Product Specifications

• Display: Enhanced LCD display
• Protection Functions:
  • Generator stator differential protection
  • 100% stator ground protection
  • Loss of field protection
  • Distance backup protection
  • Reverse power protection
• Metering Functions: Current, voltage, power, energy, frequency, power factor
• Temperature Monitoring: 12 RTD inputs
• Vibration Monitoring: 4 analog inputs
• Event Recording: 256 time-stamped events
• Waveform Capture: 12 samples per cycle, up to 128 cycles

Series

Features

• High Reliability: Suitable for high-noise industrial environments and mission-critical power systems.
• Ease of Use: Equipped with industry-leading software tools and supports local keyboard operation.
• Advanced Protection and Monitoring: Includes stator and bearing temperature monitoring, vibration monitoring.
• Flexible Configuration: Supports multiple communication protocols and interfaces, making it easy to integrate into existing or new monitoring and control systems.
• Quick Troubleshooting: Enhanced generator troubleshooting capabilities through IRIG-B time-synchronized event recording, waveform capture, and data logger.

Functions

• Generator Protection: Provides comprehensive protection functions to ensure safe shutdown of the generator in abnormal conditions.
• Real-Time Monitoring: Monitors the generator’s operating status in real-time and supports remote data access and engineering access.
• Fault Detection and Diagnostics: Reduces troubleshooting time through detailed diagnostic information.

Uses

• Small and Medium-sized Generators: Suitable for synchronous or induction generators operating at 25Hz, 50Hz, or 60Hz.
• Cogeneration Applications: Can be used as primary or backup protection.
• Industrial Automation: Integrates into DCS and SCADA systems for intelligent management.

Application Fields

• Power Industry: Power plants, substations.
• Industrial Manufacturing: Motor protection in production lines.
• Energy Management: Monitoring and management of distributed energy systems

GE IC697ALG230

Product Description

Product Parameters

• Brand: GE Fanuc
• Series: Series 90-70
• Part Number: IC697ALG230
• Input Channels: 8 (configurable for voltage or current signals)
• Input Ranges:
  • Voltage: -10VDC to +10VDC (default)
  • Current: 0.0 mA to 22.5 mA (4 to 20 mA default)
• Resolution: 16-bit ADC (Analog-to-Digital Converter)
• Accuracy: ±0.01% of full scale for voltage, ±0.05% of full scale for current
• Power Requirement: 0.8 Amps (4 watts) at +5 Volts
• Operating Temperature: -40°C to +70°C
• Humidity: 5% to 95% (non-condensing)
• Dimensions: 178 mm (W) × 102 mm (H) × 254 mm (D)
• Weight: 2.3 kg
• Communication Protocol: GE Genius Bus, optional Ethernet/IP
• Certifications: CE, UL

Product Specifications

• Input Configuration: Differential wiring, individually configurable for voltage or current signals
• Response Times:
  • 5.0% accuracy: 30 milliseconds
  • 1.0% accuracy: 42 milliseconds
  • 0.5% accuracy: 51 milliseconds
  • 0.1% accuracy: 67 milliseconds
• Linearity: ±0.02% of full scale over the entire negative to positive range
• Calibration: Factory set at 10 Volts ±2 mV for voltage, ±0.05% of full scale for current
• Update Rate: 2.4 ms to 2.8 ms
• Temperature Coefficient: ±5 PPM per °C typical, ±15 PPM per °C maximum for voltage, ±30 PPM per °C maximum for current
• Compatible Expander Modules: IC697ALG440 (Voltage Expander Module), IC697ALG441 (Current Expander Module)
• Terminals: 40 pins
• Product Lifecycle Status: Discontinued

Series

Features

• High-Precision Signal Processing: Supports 16-bit ADC for high-resolution input measurements.
• Flexible Configuration: Each of the 8 channels can be individually configured for voltage or current signals.
• Advanced Diagnostics: Built-in self-test (BIST) functionality monitors channel performance, power supply stability, and thermal conditions.
• Redundant Communication Options: Supports GE Genius Bus and optional Ethernet/IP connectivity.
• Rugged Industrial Design: Reinforced metal enclosure and conformal-coated PCBs for resistance to dust, moisture, and electromagnetic interference.
• Hot-Swappable Design: Allows replacement without powering down the PLC rack.

Functions

• Signal Conditioning: Converts analog signals from sensors to digital data for the PLC.
• Real-Time Monitoring: Provides real-time data processing for process control applications.
• System Integration: Interfaces with various field devices, including sensors and actuators.

Uses

• Oil and Gas: Monitoring pressure, flow, and temperature in pipeline networks.
• Power Generation: Measuring steam pressure and turbine vibration in power plants.
• Manufacturing: Controlling temperature in plastic extrusion lines.
• Water/Wastewater Treatment: Monitoring pH levels in treatment tanks.

Application Fields

• Oil and Gas
• Power Generation
• Manufacturing
• Water/Wastewater Treatment
• Other Industrial Automation Applications

GE IC3645LXCD1

Product Description

Product Parameters

• Input Voltage: 24V DC
• Output Voltage: 0 to 10V DC
• Rated Current: 5A
• Operating Temperature Range: -40°C to +85°C
• Dimensions: 50mm × 50mm × 25mm
• Weight: 0.72 kg

Product Specifications

• I/O Channels: 40 channels (configurable as inputs or outputs)
• Communication Protocols: RS-485, Modbus TCP
• Protection Level: IP20 (indoor protection)
• Installation: Standard DIN rail mounting

Series

Features

• High Reliability: Designed for harsh industrial environments with anti-interference and high stability.
• Flexible Configuration: Each of the 8 circuits can be configured as an input or output.
• Advanced Diagnostics: Equipped with diagnostic functions such as voltage overload detection, power-off, and no-load detection.
• User-Friendly: LED indicators on the module provide real-time feedback on errors or faults.
• Wide Operating Range: Functions effectively in a wide temperature range of -40°C to +85°C.

Functions

• Real-Time Control: Manages real-time data streams for efficient process control.
• Signal Processing: Processes signals from sensors and actuators for precise control.
• Communication: Facilitates seamless integration with other industrial components and systems through supported communication protocols.
• Monitoring and Diagnostics: Provides real-time monitoring and diagnostics to ensure system reliability.

Uses

• Manufacturing: Controlling robots, conveyor systems, and other automated equipment.
• Energy and Utilities: Monitoring and controlling power generation, transmission, and distribution systems.
• Water and Wastewater Treatment: Automating and optimizing water treatment processes.
• Automotive: Managing production lines and robotic systems.
• Process Control: Chemicals, pharmaceuticals, food processing.

Application Fields

• Manufacturing
• Energy and Utilities
• Water and Wastewater Treatment
• Automotive
• Process Control

GE 8502-BI-DP

Product Description

Product Parameters

• Model Number: 8502-BI-DP
• Type: Bus Interface Module (BIM)
• Protocol: Profibus-DP
• Communication Speed: Up to 6 Mbaud
• Power Supply: 24V DC
• Dimensions: Industrial standard (85mm x 45mm x 23mm)
• Weight: Approximately 0.35kg
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% (non-condensing)

Product Specifications

• Compliance: Meets Profibus-DP protocol standards.
• Reliability: Suitable for harsh industrial environments.
• Configuration: Supports multiple configuration options.
• HART Support: Supports HART protocol for detailed device parameters.
• Diagnostics: Provides extended diagnostic information for module and channel status.

Series

Features

• High-Speed Data Acquisition: Capable of high-speed data acquisition to meet real-time control requirements.
• Flexible Configuration: Can be configured through software to adapt to different application needs.
• HART Support: Facilitates communication with HART devices.
• Powerful Diagnostic Functions: Aids in quickly locating faults.

Functions

• Connects I/O Modules and Host: Establishes a communication bridge between I/O modules and the Profibus-DP host.
• Data Transmission: Transmits data collected by I/O modules to the host.
• Configuration Management: Configures parameters of I/O modules.
• Diagnosis: Monitors the status of modules and channels.

Uses

• Process Control Systems: Collects process variables and implements process control.
• Data Acquisition Systems: Gathers field data for analysis.
• Equipment Monitoring Systems: Monitors the operating status of equipment.

Application Fields

• Process Control: Used in the process control of various industries.
• Data Acquisition: Used for data acquisition and analysis.
• Equipment Monitoring: Used to monitor the status of equipment

GE IC670MDL644

Product Description

Product Parameters

• Model Number: IC670MDL644
• Manufacturer: GE Fanuc
• Series: Field Control
• Input Voltage: 24V DC (0-30V DC range)
• Number of Inputs: 16 channels
• Input Current: 8 mA at 24V DC
• Input Impedance: 3K ohms (typical)
• Isolation:
  • 250V AC continuous isolation from input to logic
  • 1500V AC isolation from input to frame ground (1 minute)
• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% (non-condensing)
• Dimensions: 224mm × 91mm × 119mm (8.82″ × 3.58″ × 4.69″)
• Weight: 1.0 kg (2.2 lbs)
• Power Consumption: 77 mA (typical)
• Communication Protocol: Genius Bus (153.6 Kbit/s)
• Mounting Type: Panel mount or DIN rail
• Certifications: UL Listed, CE, CSA

Product Specifications

• Signal Acquisition Speed: High-speed
• Response Time:
  • On state: 12-20 ms
  • Off state: 25-40 ms (typical)
• LED Indicators:
  • 1 LED per input channel
  • PWR LED for power status
  • COM LED for communication status
  • FAULT LED for fault indication
• Hot-Swap Capability: Yes (requires BIU firmware version ≥2.1)
• Compatibility: Compatible with other Field Control series modules and GE Fanuc systems.

Series

Features

• High-Precision Signal Processing: Supports 24V DC positive and negative logic inputs.
• Wide Operating Temperature Range: Ensures reliability in harsh industrial environments.
• Modular Design: Easy to install and maintain, with support for hot-swapping.
• Smart Diagnostics: Real-time monitoring of power, communication, and fault status via LED indicators.
• Redundant Design: Ensures high reliability in critical applications.

Functions

• Data Acquisition: Collects and processes digital signals from various sensors and switches.
• System Integration: Integrates seamlessly with other GE Fanuc modules and systems.
• Real-Time Monitoring: Provides real-time status updates and fault detection.
• Communication: Facilitates data exchange with the main control system via the Genius Bus protocol.

Uses

• Manufacturing: For monitoring and controlling production lines.
• Power Generation: In power plants for equipment monitoring and control.
• Oil & Gas: For monitoring valves, pressure switches, and emergency shutdown signals.
• Water and Wastewater Treatment: For monitoring pump status and level switches.
• Process Control: In industries such as pharmaceuticals and food processing.

Application Fields

• Manufacturing
• Power Generation
• Oil & Gas
• Water and Wastewater Treatment
• Process Control

GE BK698A201S12

Product Description

Product Parameters

• Model Number: BK698A201S12
• Manufacturer: General Electric (GE)
• Series: BK Series
• Operating Voltage: 110-240V AC
• Output Voltage: 24V DC
• Output Current: 10A
• Efficiency: 95%
• Operating Temperature Range: -40°C to 70°C
• Dimensions: 150mm × 100mm × 50mm
• Input Channels: 4 channels
• Input Range: -10V to +10V
• Conversion Resolution: 12-bit (4096 levels)
• Conversion Speed: Single channel 1ms, overall 4ms
• Humidity Range: 10% to 95% (non-condensing)

Product Specifications

• Enclosure Material: Metal
• Color: Grey
• Installation Method: Wall-mounted
• Certifications: CE, UL

Series

Features

• High-Precision Signal Processing: Supports 4-channel analog voltage input with a 12-bit resolution.
• Industrial-Grade Reliability: Wide operating temperature range and humidity tolerance, suitable for harsh industrial environments.
• Modular Design: Easy to install and maintain, with support for various interface types.
• Smart Energy Management: Optimizes the coordination of power generation and storage devices in microgrid systems.

Functions

• Data Acquisition and Processing: Real-time data acquisition and processing for high-precision control.
• Device Control: High-precision control of servo motors and other devices.
• System Monitoring: Monitoring of various parameters in industrial automation systems.

Uses

• Industrial Automation: For precise control and monitoring in manufacturing processes.
• Energy Management: Optimizing power generation and storage in microgrid systems.
• Process Control: Monitoring and controlling parameters in industries such as pharmaceuticals and food processing.

Application Fields

• Manufacturing
• Energy Industry
• Process Control
• Other Industrial Automation Applications
