Allen-Bradley 1794-IE12 Analog Isolated Output Module

Model Number:1794-IE12

Manufacturer:Allen-Bradley

Type:Analog Isolated Output Module

Channels:16

Voltage Rating:24 Vdc

Current Rating:20 mA

Input Resistance:Open Collector

Isolation Rating:2 kV AC

Operating Temperature:-40°C to +70°C

Dimensions (WxHxD):2.5

x:1.25″

Weight:0.5 lb

    Engineered with precision, the Allen-Bradley 1794-IE12 Analog Isolated Output Module offers unparalleled reliability and performance in industrial automation environments. Its robust design ensures seamless integration with various control systems, enhancing operational efficiency.

    Featuring an isolation rating of 2500V, this module provides a high level of safety by preventing any direct current path between the input and output circuits, crucial for systems where electrical isolation is required.

    With its 8-channel capacity, each capable of delivering currents from 0.0 mA to 20.0 mA or voltage ranges from 0V to 20V, the 1794-IE12 is versatile enough to handle a wide array of control tasks in manufacturing, HVAC, and process control applications.

    The 12-bit resolution ensures accurate data representation, minimizing errors in measurement and control processes. This precision is vital for achieving optimal performance and minimizing waste in industrial settings.

    Operable within a temperature range of -20°C to +55°C, the Allen-Bradley 1794-IE12 is built to withstand harsh industrial environments, ensuring continuous operation under varying conditions without compromising on performance.
