Model Number:4PP420.1043-75
Brand:B&R
Operating Voltage:18 to 30 VDC
Nominal Current:0.5 A
Power Consumption:Typ. 12 W
Display Size:7 inch
Display Technology:QVGA color TFT
Resolution:320 x 240 pixels
Touchscreen Type:Resistive
Communication Interfaces:ETH 10/100, RS232, 2x USB
Expansion Slot:1 aPCI slot
Storage Slot:CompactFlash slot (type I)
Memory:128 MB SDRAM, 512 KB SRAM
Protection Rating:IP65 (front side)
Weight:1700 g
Dimensions:7″ x 3″ x 9″
The B&R 4PP420.1043-75 Power Panel offers advanced functionality for monitoring and controlling industrial processes. Its robust design includes an intuitive 7-inch color TFT display with a responsive resistive touchscreen interface. Equipped with 128MB SDRAM and 512KB SRAM, this power panel ensures fast data processing and storage capabilities. Additionally, it supports CompactFlash storage for extended data logging needs. With a variety of connectivity options such as Ethernet, RS232, and two USB ports, integration with existing systems is seamless. The front-side IP65 protection rating makes it suitable for use in harsh industrial environments. Installation is straightforward with the option to use either 0TB103.9 screw clamps or 0TB103.91 cage clamps, which must be purchased separately. Ideal for use in manufacturing, automotive, food & beverage, and packaging industries.
