Manufacturer:General Electric
Model:DS3800HRCA1D1B
Category:Speedtronic MARK IV Control Board
Terminal Plugin Type:Dark terminal plugin sideways along one edge
Mounting Method:Clips provided on the board and two tiny screws
LEDs:One amber and four red LEDs
Jumper Ports:Two groups of jumper ports for customizable current flow
Diodes:Variety of diodes for enhanced performance
The DS3800HRCA1D1B is meticulously crafted for industrial control systems, particularly within the realm of gas and steam turbine management. Designed for seamless integration with the Speedtronic Mark IV platform, this circuit board ensures reliable operation under demanding conditions. Its compact design allows for efficient space utilization without compromising functionality.
This board features a dark terminal plugin along one edge, which can connect to another board or be held securely in place using the mounting clips and two tiny screws included. Equipped with one amber LED and four red LEDs, it provides clear visual feedback on the system’s operational status, aiding in quick troubleshooting and maintenance.
The DS3800HRCA1D1B also includes two groups of jumper ports with small caps, enabling users to adjust current flow as needed for specific applications. Additionally, its robust construction ensures durability and longevity, making it a reliable choice for critical turbine control operations.
