Koyo D4-PULS-1 Single Axis Pulse Module

Power Supply Voltage:12V DC

Operating Temperature Range:-20°C to +70°C

Output Pulse Frequency:Up to 10kHz

Communication Interface:RS-232C

Input Current Consumption:Max. 10mA

Dimensions (WxDxH):40mm x 40mm x 16mm

    The Koyo D4-PULS-1 Single Axis Pulse Module is an essential component for enhancing the precision and performance of industrial automation systems. Its compact design ensures minimal space usage on the factory floor while its robust construction withstands harsh environmental conditions.

    This pulse module offers an ultra-fast response time of less than 1 millisecond, enabling seamless synchronization with high-speed machinery and processes. Its wide operating voltage range from 12V to 24V DC makes it compatible with various power sources commonly found in industrial environments.

    With an accuracy of ±0.05%, the Koyo D4-PULS-1 guarantees precise position control, ensuring that each movement is executed with utmost precision. This level of accuracy is crucial for applications requiring high repeatability, such as robotic assembly lines or CNC machines.

    Featuring an open collector output type capable of delivering up to 1A at 24VDC, this module provides reliable current delivery to actuators or other connected devices. The included wiring harness facilitates easy installation and integration into existing systems.

    Designed for a temperature range of -20°C to +70°C, the Koyo D4-PULS-1 is suitable for use in extreme industrial conditions. Its lightweight design (0.1kg) makes it easy to handle during installation and maintenance operations.
