Module Type:IGBT
Rated Current (A):30
Rated Voltage (V):1200
Peak Current (A):50
Thermal Resistance (°C/W):1.5
Cooling Method:Thermally Enhanced
Operating Temperature Range (-°C to +°C):-40°C to +170°C
Insulation Resistance (Ω):≥ 10^12
Max. Repetitive Peak Reverse Voltage (V):1700
Designed for high-reliability industrial applications, the SEMIKRON SKD30/12A1 IGBT module offers superior performance and efficiency.
This module features a robust press-fit design for secure mounting and enhanced thermal management.
With a rated voltage of 1200V and a rated current of 30A, this module can handle demanding power conversion tasks.
The module includes 12 pins for easy integration into existing systems and comes with a N-channel configuration.
The maximum gate emitter voltage of ±20V ensures precise control over the IGBT, optimizing performance in various applications.
