Waveform Types:Sine, Square, Triangle, Pulse, Arbitrary
Frequency Range:1 μHz to 20 MHz
Amplitude Range:20 mVpp to 10 Vpp
Resolution:14-bit
Output Impedance:50 Ω
Memory Depth:2 MSamples
Sampling Rate:250 MSa/s
Interface:USB, LAN, GPIB
The Tektronix 5A22N Arbitrary Waveform Generator offers unparalleled precision and reliability in generating complex waveforms for advanced testing scenarios. Built with state-of-the-art technology, this generator delivers exceptional performance with a frequency range up to 240 MHz, ensuring accurate and repeatable results in demanding environments. Its wide output amplitude range from 2 Vpp to 10 Vpp allows for versatile applications across multiple industries. With 14-bit resolution and a sample rate of 2 GSa/s, users can create intricate signals with minimal distortion. The extensive memory depth of 256 MSamples ensures long-duration waveform generation without degradation. Additionally, phase shift control ranging from 0 to 360 degrees provides flexibility in signal manipulation. Designed with ease of use in mind, the intuitive user interface enables quick setup and operation, making it an indispensable tool for engineers and researchers. Whether you are conducting telecommunications tests, performing electronics diagnostics, or simulating automotive systems, the Tektronix 5A22N stands out as a reliable and precise solution.
