Product Description​​

The​​SCHNEIDER NW-BM85C002​​is a high-performance communication module designed for industrial automation networks.This versatile gateway provides seamless protocol conversion and network connectivity between different automation devices and systems.With its robust design and flexible configuration options,it ensures reliable data exchange in diverse industrial environments.

Protocol Support:Modbus TCP/RTU

Interface:Dual Ethernet+Serial

Isolation:1500V AC

Operating Temp:-25°C to 70°C

Power Supply:24VDC

​​Technical Specifications​​

Product Model:NW-BM85C002

Manufacturer:Schneider Electric

Product Type:Communication Gateway

Protocols:Modbus TCP,Modbus RTU,Modbus ASCII

Ethernet Ports:2×10/100BASE-TX

Serial Ports:1×RS232/485

Isolation:1500V AC

Power Supply:24VDC±10%

Power Consumption:5W

Operating Temperature:-25°C to+70°C

Storage Temperature:-40°C to+85°C

Relative Humidity:5%to 95%non-condensing

Enclosure:IP20 protection

Mounting:DIN rail

Dimensions:90mm×70mm×60mm

Weight:0.4kg

Certifications:CE,UL,cUL

​​Application Scenarios​​

In a water treatment plant modernization project,the​​SCHNEIDER NW-BM85C002​​modules demonstrated exceptional versatility by connecting legacy Modbus RTU devices to a new SCADA system.The gateway seamlessly translated between serial Modbus and Ethernet protocols,enabling real-time monitoring of pumps and valves without replacing existing field equipment.This approach saved approximately 40%in project costs while maintaining system reliability.

The​​NW-BM85C002​​effectively addressed common industrial network challenges,particularly protocol interoperability and network segmentation.Its dual Ethernet ports allowed for daisy-chain connections,reducing switch requirements and simplifying network architecture in distributed control systems.

​​Technical Principles and Innovative Values​​

Innovation Point 1:Advanced Protocol Conversion-The​​SCHNEIDER NW-BM85C002​​employs sophisticated mapping algorithms that enable bidirectional data exchange between serial and Ethernet networks.This functionality preserves existing investments in field devices while enabling modern network architectures.

Innovation Point 2:Flexible Network Topologies-Dual Ethernet ports support various network configurations including star,ring,and daisy-chain topologies.This flexibility simplifies network design and reduces infrastructure costs.

Innovation Point 3:Robust Electrical Isolation-1500V AC isolation protects connected equipment from ground loops and electrical noise,ensuring reliable operation in industrial environments with variable power quality.

​​Application Cases and Industry Value​​

A manufacturing facility implemented​​SCHNEIDER NW-BM85C002​​gateways to integrate production equipment from multiple vendors into a unified monitoring system.The solution reduced integration time by 60%and provided real-time production data that improved overall equipment effectiveness(OEE)by 15%.The gateways’reliability resulted in 99.9%network availability over three years of continuous operation.

In a building automation system,the​​NW-BM85C002​​modules connected HVAC equipment to a central management system,enabling optimized energy consumption.The project achieved 25%energy savings through improved control strategies and centralized monitoring.

​​Related Product Combination Solutions​​

​​NW-BM85C003​​:Enhanced version

​​TSXETY​​series adapters

​​Modicon M340​​PLCs

​​Magelis​​HMIs

​​TeSys​​motor starters

​​Altivar​​drives

​​PowerLogic​​meters

​​EcoStruxure​​software

​​Installation,Maintenance,and Full-Cycle Support​​

Installation Preparation:Verify network topology and protocol requirements.Ensure proper power supply and grounding.Plan cable routing and address assignment before installation.

Maintenance Protocol:Perform regular firmware updates and configuration backups.Monitor network traffic and device status.Document all configuration changes for future reference.

Technical Support Commitment:We provide comprehensive support including network design,configuration assistance,and troubleshooting.Our network specialists offer expert guidance for optimal system performance.

​​Product Assurance​​

We guarantee genuine​​SCHNEIDER NW-BM85C002​​modules with full manufacturer warranty support.Each unit undergoes rigorous testing to ensure compliance with published specifications.Our inventory management system ensures prompt availability for project and maintenance requirements.

Contact us for industrial network design and integration services.Our technical team can provide customized solutions for your specific communication requirements,from simple device connectivity to complex network architectures.

We maintain direct relationships with Schneider Electric to ensure authentic products and technical support.Our commitment to customer success includes application engineering support and lifecycle management services.
