Product Overview
TheWoodward 5466-1000is an advanced digital governor controller designed for precision speed and load control in critical turbine and engine applications.This sophisticated control module represents Woodward’s leadership in rotating equipment control technology,providing reliable regulation for gas turbines,steam turbines,and diesel engines across various industries.TheWoodward 5466-1000integrates state-of-the-art processing capabilities with robust industrial construction to deliver exceptional control performance in demanding operating conditions.As a central component in prime mover control systems,this controller ensures stable operation,optimal performance,and equipment protection through advanced control algorithms and comprehensive system monitoring.
Engineered for maximum reliability,theWoodward 5466-1000serves as the intelligent core of control systems in power generation,mechanical drive,and marine propulsion applications.The module receives multiple process inputs including speed,temperature,pressure,and position feedback,processing these signals through configurable control algorithms to generate precise output signals to actuators and fuel systems.TheWoodward 5466-1000is designed to maintain precise control during normal operation while providing critical protection during abnormal conditions,making it an essential component for applications where equipment safety and operational reliability are paramount.Its modular design and flexible configuration options allow for customization to meet specific application requirements across different industries and operating scenarios.
Technical Specifications
Parameter Name
Parameter Value
Product Model
5466-1000
Manufacturer
Woodward
Product Type
Digital Governor Controller
Input Power
24V DC nominal(18-36V DC range)
Processor
High-performance 32-bit microprocessor
Memory
Flash memory for program storage
Analog Inputs
8 channels,16-bit resolution
Digital Inputs
16 channels,configurable
Analog Outputs
4 channels,12-bit resolution
Digital Outputs
8 channels,relay and transistor
Speed Sensing
Multiple MPU inputs,5V RMS minimum
Communication
Dual Ethernet,RS-232/485,USB
Control Modes
Isochronous,Droop,Base Load
Operating Temperature
-40°C to+85°C
Storage Temperature
-55°C to+105°C
Enclosure Rating
NEMA 4X/IP66
Dimensions
400mm x 300mm x 80mm(WxHxD)
Weight
4.5 kg(10 lbs)
Certifications
UL,CE,ATEX,DNV-GL
Main Features and Advantages
Advanced control capability is the defining characteristic of theWoodward 5466-1000.The controller incorporates sophisticated PID control algorithms with adaptive gain scheduling that automatically adjusts control parameters based on operating conditions.This ensures optimal performance across the entire operating range from startup to full load.TheWoodward 5466-1000supports multiple control modes including isochronous speed control for generator applications,droop control for load sharing,and base load control for mechanical drive applications.The module’s high-speed processing and precise signal resolution enable it to maintain tight control during rapid load changes and transient conditions.
Comprehensive system integration and communication capabilities provide significant operational advantages.TheWoodward 5466-1000features multiple communication ports including dual Ethernet interfaces for network connectivity,RS-232/485 for legacy system integration,and USB for local configuration.This extensive connectivity allows seamless integration with SCADA systems,distributed control systems,and plant networks.The controller’s modular I/O structure supports a wide range of signal types and can be expanded with additional I/O modules to meet specific application requirements.Built-in diagnostic functions continuously monitor system health and provide detailed information for predictive maintenance,reducing downtime and improving system reliability.
Robust construction and environmental tolerance ensure reliable operation in challenging conditions.TheWoodward 5466-1000is housed in a rugged enclosure rated NEMA 4X/IP66,providing protection against dust,moisture,and corrosive environments.The wide operating temperature range allows deployment in extreme climates without additional environmental controls.Redundant power supply inputs and fault-tolerant design features ensure continuous operation even during power disturbances or component failures,making theWoodward 5466-1000ideal for critical applications where uninterrupted operation is essential.
Application Field
TheWoodward 5466-1000is extensively deployed in power generation applications where precise speed control is critical for grid stability and equipment protection.In gas turbine power plants,the controller manages startup sequences,speed acceleration,and load control while providing overspeed protection and temperature monitoring.TheWoodward 5466-1000is particularly valuable in combined cycle plants where it coordinates operation between gas turbines and steam turbines to optimize overall plant efficiency.In distributed generation applications,the controller ensures reliable operation of backup generators in critical facilities such as hospitals,data centers,and industrial plants.
In the oil and gas industry,theWoodward 5466-1000controls compressor and pump drives in pipeline transmission,gas processing,and refinery applications.The controller’s precise speed regulation ensures efficient operation of centrifugal compressors while protecting against surge conditions.Marine propulsion systems represent another significant application area,where theWoodward 5466-1000governs main engines and auxiliary generators on various vessels including offshore supply ships,tankers,and cruise liners.The controller’s robust design withstands the challenging marine environment while providing precise control for maneuvering and cruising operations.Industrial mechanical drive applications including sugar mills,paper mills,and mining equipment also benefit from the reliable performance of theWoodward 5466-1000in controlling critical rotating machinery.
Related Products
5466-2000:Enhanced version with expanded I/O capacity and processing power
5466-3000:High-availability version with redundant processor configuration
2301D:Digital governor for smaller engine and turbine applications
PRO-DIGITAL:Multi-loop process controller compatible with5466series
NETWORK-Interface:Communication gateway for system integration
Actuator-5466:Electro-hydraulic actuator designed for5466-1000compatibility
I/O-Expansion:Additional I/O modules for system expansion
Display-Local:Local operator interface for5466-1000configuration and monitoring
Installation and Maintenance
Pre-installation preparation:Before installing theWoodward 5466-1000,verify that the mounting location provides adequate space for wiring,ventilation,and maintenance access.Ensure the mounting surface is structurally sound and properly grounded.Verify that the power supply meets voltage requirements and has sufficient capacity for the controller and connected devices.Check environmental conditions including temperature,humidity,and potential exposure to corrosive substances to ensure they remain within specified limits.Have all necessary mounting hardware,tools,and termination equipment ready before beginning installation.
Maintenance recommendations:Regular maintenance for theWoodward 5466-1000includes periodic inspection of electrical connections,cleaning of ventilation paths,and verification of control calibration.Monitor system performance through built-in diagnostic functions and maintain comprehensive records of operating parameters and maintenance activities.Perform regular functional testing of control and protection systems to verify proper operation.Keep firmware updated to the latest version and backup configuration data regularly.Follow Woodward’s recommended maintenance intervals and procedures to ensure optimal performance and extended service life.Establish a preventive maintenance schedule based on operating hours and environmental conditions to address potential issues before they affect system operation.
Product Guarantee
We guarantee that everyWoodward 5466-1000digital governor controller meets manufacturer specifications for performance and reliability in critical control applications.Our commitment to quality ensures that each unit undergoes comprehensive testing and verification before shipment.We provide expert technical support for system design,installation,configuration,and troubleshooting to ensure successful implementation in your control system.By choosing us as your supplier,you receive genuine Woodward products backed by comprehensive technical support and warranty coverage.Our team of experienced engineers is available to assist with integration challenges and optimize controller performance for your specific application requirements,ensuring maximum reliability and operational efficiency throughout the equipment lifecycle.
